PVR
Humax PVR-8000T
Personal Video Recorder
Quick Setup (Plug-n-Play Installation)
MPEG2 Digital & Fully DVB-T Compliant
200 Channel storage
5 Favourite groups
Subtitle supports EBU & DVB subtitle
Teletext supports by VBI insertion
Dolby Digital Audio Output
Various Games
Universal Remote Control Compatible with most
TV’s
H U
RF-Modulator
RF Output Connector
(Loop throughout)
75Ω, IEC 169-2, Male
Frequency
470 MHz ~ 862 MHz
Output Channel
CH21-69 for Modulator
TV Standard
PAL B/G/I selectable by menu
SCART
TV SCART
Video Output (CVBS, RGB, S-Video)
Audio Output (Max. 2 Vrms)
VCR SCART
Video Input (
CVBS, RGB, S-Video)
Video Ou
tput (CVBS, S-Video)
Audio Output (Max.2 Vrms)
RCA
VIdeo RCA
1 Output
Audio RCA
2 Output (Left, Right)
Data Port
RS-232C
3-pin
Front
Buttons
10 Keys (Standby/On, TV/Radio,
MENU, GUIDE, EXIT, OK/CH. List,
Arrow keys)
Indicators
1 LEDs (Standby/On)
Display
4 digit 7-segment
Rear
Main Power cab
le
Fixed Type
Tuner
1 Antenna Input
SCARTs
1 for TV, 1 for VCR
RCA
1 Video Output
2 Audio Output (Left & Right)
Data Port
1 RS-232C (3 pin type)
Power Switch
Yes
RF Modulator
1 Output
S/PDIF
1 Output
Physical Specification
Size (WxHxD)
370x60x262
Weight (net)
2.7kg without HDD
OPerating Temperature
0°C~+45°C
Storage Temperature
-10°C ~ +70°C
Accessories
Universal RCU, User’s Manual,
2 Batteries (AAA), Scart Cable
SCI TEQ
Phone: 08 9409 6677 Fax: 08 9309 5210
Web: www.sciteq.com.au
Email: sales@sciteq.com.au
System Resource
CPU
STi5518
Flash
4MB
SDRAM
24MB
EEPROM
8KB
HDD Storage
80GB
Power Supply
Input Voltage
AC 90-250, 50/60Hz
Type
Switching Mode Power Supply
Power Consumtion
Max. 30W (without HDD)
Standby: Max. 8W
Protection
Separate internal fuse &
Lightning protection
Demodulator
Waveform
OFDM
Mode
2K, 8K
Codes Rates
1/2, 2/3, 3/4, 5/6, 7/8
Guard Intervals
1/4, 1/8, 1/16 & 1/32
Tuner & Channel
1 Input Connector
IEC 169-2, Female
Frequency Range
48.5MHz~226.5MHz(VHF)
470MHz~862MHz (UHF)
Signal Level
-10~-70 dBm
Video Decoder
Transport stream
MPEG2 ISO / IEC 13818
Profile Level
MPEG2 MP@ML
Input Rate
Max. 15 Mbit/s
Video Formats
4:3, 16:9 Letterbox (Default)
Video Ouput
CVBS (Default), RGB, S-Video
Video Resolution
Max. 720 x 576
Audio Decoder
Audio Decoding
MPEG/MusiCam Layer I & II
Audio Mode
Single/Dual Mono/Stereo
/Joint stereo
Stock No. 105011
