Administering Routes 9-5
■ Distance
The distance in hops to the destination network
■ Interface
The defined interface number
■ State
The status (good, suspect, bad, or really bad) of each route
Displaying the
Routing Table
You can display the routing tables for the EFSMs in a system to determine
which routes are configured and if they are operational.
To display the contents of the routing table:
1 From the Administration Console top-level menu, enter:
appletalk route display
2 Enter the slot(s) of the EFSM(s) for which you want to display the routing
table. Separate non-consecutive slots with commas (,). Enter a consecutive
series of slots using a dash (-).
An example of a routing table display is shown below:
Top-Level Menu
system
ethernet
fddi
tokening
bridge
ip
ipx
➧appletalk
snmp
analyzer
script
logout
interface
➧route
aarp
zone
forwarding
checksum
ping
statistics
➧display
flush
Slot 2 - DDP forwarding is enabled.
Network Range Distance Interface State
1-1 10 1 good
3 4 1 good
10-14 6 1 good
15-19 7 1 good
61 6 1 good
100-100 10 1 good
201-300 7 1 good
2010-2015 2 1 good
10009-10009 5 1 good
10010-10010 7 1 good
10060-10060 8 1 good
10110-10113 5 1 good
10116-10117 5 1 good
10118-10118 6 1 good
10119-10119 4 1 good
10120-10120 7 1 good
10122-10122 9 1 good
10310-10329 10 1 good
10410-10410 8 1 good
11010-11019 9 1 good
