13
System LED indicators
This section discusses the different status LED indicators located on the:
Front panel
Hot-plug HDD carrier
LAN port
Knowing what each LED indicator signifies can aid in problem
diagnosis and troubleshooting.
Front panel LED indicators
The LED indicators (green) mounted on the front panel allow the
constant monitoring of the system’s power status and drive activity.
No. Indicator Status Description
1 ODD activity Blinking There is an ongoing ODD activity.
2 Power On The system is powered on.
Blinking The system is in ACPI sleep mode.
3 HDD activity Blinking There is an ongoing HDD activity.
4 FDD activity Blinking There is an ongoing FDD activity.
