14. SPECIFICATIONS
Model: ACT-IR220L+/ACT-IR220L/ACT-IR200L
Carrier: Infrared radiation (peak wavelength: 850 to 1050 nm)
Sub-Carrier: 500 KHz for SHARP ASK-IR and ASK(37KHz) for TV remote spec.(IR200L
only)
Communication
Distance:
IR200L From 0 to 80 cm. For best results, from 20 to 60 cm (7.9 in to1 ft. 11.6
in)
IR220L From 0 to 250 cm. For best results, from 10 to 150 cm (3.95 in to 4 ft.
11.05 in)
SHARP ASK-IR: IrDA-IR:
Baud Rate: 9600 bps to 38.4K bps (IR200L only) 9.6,19.2,(38.4),57.6,115.2K bps (IR200L/220L+)
Parity Bit: Odd None
Data: 8 bit 8 bit
Stop Bit: 1 bit 1 bit
Error Check: Check Sum CRC
Serial Interface: Cable Interface (to host computer)
Signal Level: RS-232 Standards
Connector: DB-9 female connector
Power Source: PC RS-232 Serial Port
Power Consumption: 0.30mW (11mA max.)
Operating
temperature:
0
o
C to 40
o
C (32
o
F to 104
o
F)
Dimensions:
2.0 in. L x 1.63 in W x 0.62 in H (51mm x 41mm x 16mm)
Weight: 2.0 oz (54 gr.)
Accessories: User Manual
Optional
Accessories:
DB9/DB25 Converter ; IR Software for Windows 95/98/ME/2000
Pin Assignments of Serial Interface DB9 female connector
Pin Name Symbol I/O Function
2 Receive Data RXD I Input signal
3 Transmit Data TXD O Output signal
4 Data Terminal Ready DTR O For data link to build up and maintain
5 Signal Ground GND - Reference ground (0V) for all signals
7 Request to send RTS O Output signal from host computer
8 Clear to send CTS I Input signal to host computer
