6739380EN/JC - Page 45
Inverter On/Off commands
Display for the inverter On/Off commands
Direct access to the function by pressing
the "I/O" button .
This screen is displayed if the inverter is already
off. It is a prompt to press the "*" button to
confirm start-up. During start-up, the following
screen is displayed:
This screen is displayed if the inverter is on. It is
a prompt to press the "*" button to confirm
shutdown.
If the transfer to Mains 2 conditions are not
correct, the following screen is displayed a few
seconds:
Following confirmation of the command, the
system automatically returns to the initial
screen.
PROCESSING
…
COMMAND REFUSED
TRANSFER IMPOSSIBLE
Language, display contrast and buzzer volume settings
Direct access to the function by pressing the
"settings" button.
Selection of the display language: English,
French, German, Italian, Spanish, Dutch,
Swedish, Finnish, Portuguese.
This screen is a prompt to set the display
contrast by successively pressing the ">" button.
When the setting is confirmed by pressing the
"*" button, the system goes on to the buzzer.
When this screen is displayed, the buzzer
automatically turns on. Press the ">" button
several times to adjust the volume. After
confirmation of the buzzer volume by the "*"
button, the system automatically returns to the
initial screen.
Display of the settings selection screens
◗ if a "Soft Tunor" session is in
progress (initiated by after-sales
support technicians), pressing the "I/O"
button produces the message:
COMMAND INVALID
SOFT TUNOR
These commands may be accessed
only via the master display. When the
"I/O" button is pressed, the series of
screens in the figure opposite is
displayed.
Note:
◗ these commands do not concern the
Static Switch Cubicle. The "I/O" button
on the "static switch" cubicle produces
the message:
COMMAND INVALID
STATIC SWITCH MODUL
◗ the "I/O" button on a slave display
monitor produces the message:
COMMAND INVALID
ON SLAVE DISPLAY
◗ if the On/Off commands have not
been validated (by the after-sales
support technicians), pressing the "I/O"
button produces the message:
COMMAND INVALID
CONFIGURATION
These settings may be accessed by
pressing the "settings" button.
The series of screens in the figure
opposite is displayed.
*
*
START INVERTER ?
=YES >=ESCAPE
or
initial screen
initial screen
*
STOP INVERTER ?
=YES >=ESCAPE
*
LANGUAGE = ENGLISH
=CONFIRM.
initial screen
*
DISPLAY CONTRAST
>=SELECT =CONFIRM.
*
BUZZER VOLUME
>=SELECT =CONFIRM.
*
*
*
*
"Monitor" alphanumeric display (cont.)
