2. WEB Configuration
Open the web browser, enter the local port IP address of this device, which defaults
at http://192.168.1.10, and click “Go”, a username and password window will
appear.
The default username & password are admin & admin, in respectively.
To configure your DiskMaster, you will need to use the web browser,
enter the IP address and then use the web configuration for further
setup. To find out the IP address (if You changed) of your device once it
is connected to the network, there are several different ways as
described on the following pages.
Use the Setup utility included on the CD (CDRom:\Utility\setup.exe).
This will list the device automatically and allow you to access the web
configuration interface with a simple click of your mouse.
You will get a status report web page when login successfully. At the configuration
homepage, the left navigation page where bookmarks are provided links you
directly to the desired setup page, including:
System Status [System Status]
Configuration [Networking, Basic, Server Preference, Admin Password,
Firmware Upgrade, Backup/Restore, Factory Defaults,
Reboot/Shutdown, Remote Package]
Share Management [Share Folder, User Management]
Backup [Scheduling Backup]
Disk Utility [Disk Information, Disk Mode, Format Disk]
System Logs [SysLog Server, System Logs]
Service Configuration [iTunes Server, UPnP Server, BT Client, NAS
Printer]
Click on the desired item to expand the page in the main navigation page.
