One Computer Using Four Printers
7
First, set the switches on the AutoSwitch as below:
(New Style)
End View
Spare Power Jack for Optional
9VDC 500 mA Power Supply
SW 3 SW 4 TimeOut
OFF OFF 60 Seconds
OFF ON 25 Seconds
ON OFF 10 Seconds
ON ON 5 Seconds
Manual
Select button
DIP Switches
ON: DOWN
OFF: UP
Spare Power Jack for Optional
9VDC 500 mA Power Supply
Manual
Slide Switch
DIP Switches
ON: DOWN
OFF: UP
SW3 TimeOut
ON 15 Seconds
OFF 30 Seconds
SW2 Form Feed
ON Disabled
OFF Enabled
Set SW1 and SW2 to ON for 1-4 Mode.
Form feed is enabled only when your printer does not eject paper after printing in DOS.
Set SW3 and SW4 for TimeOut:
(Old Style)
End View
Set SW1 to ON for 1-4 MODE.
Form feed is enabled only when your printer does not eject paper after printing in DOS.
En
