NOTE: Tank cover included. For optimum cleaning results, Branson offers a line of accessories including perforated trays,
solid trays, beaker covers and support racks for your application needs.
Ordering Part No. Voltage Model 1800 Model 2800 Model 3800 Model 5800 Model 8800
120 V CPX1800H CPX2800H CPX3800H CPX5800H CPX8800H
Part No. CPX-952-118R CPX-952-218R CPX-952-318R CPX-952-518R CPX-952-818R
230/240 V CPX1800H-E CPX2800H-E CPX3800H-E CPX5800H-E CPX8800H-E
Part No. CPX-952-138R CPX-952-238R CPX-952-338R CPX-952-538R CPX-952-838R
Specifications
Model 1800 Model 2800 Model 3800 Model 5800 Model 8800
Tank Capacity
Liters/Gallons 1.9/0.5 2.8/0.75 5.7/1.5 9.5/2.5 20.8/5.5
Tank Size (L/W/D)
Inches 6 x 5.5 x 4 9.5 x 5.5 x 4 11.5 x 6 x 6 11.5 x 9.5 x 6 19.5 x 11.5 x 6
mm 150 x 140 x 100 230 x 140 x 100 290 x 150 x 150 290 x 240 x 150 495 x 290 x 150
Overall Size (L/W/D)
Inches 9.9 x 12 x 11.9 13.3 x 12 x 11.9 15.6 x 12.5 x 14.8 15.6 x 15.8 x 14.9 23.5 x 18.3 x 15.4
mm 251 x 304 x 302 337 x 304 x 302 397 x 317 x 377 397 x 401 x 378 596 x 466 x 391
Weight
Pounds/Kilograms 7/3.2 9/4.1 12/5.4 14/6.4 26/11.8
Frequency 40 kHz 40 kHz 40 kHz 40 kHz 40 kHz
Drain No No Yes Yes Yes
CPXH Series (Digital timer with heat)
CPXH Series
© Branson Ultrasonics Corporation 2013.
The Emerson logo is a trademark and service mark
of Emerson Electric Co.
Printed in the U.S.A.
BCL-0001-12
• High-temp safety alarm indicator for protection from unit
overheating.
•
Temperature calibration is user accessible through
front panel.
• Controls are located above and behind the cleaning tank
in an easily accessible control tower panel, and raised
above the tank to avoid damage from cleaning solutions.
•
Convenient built-in pour drains are featured on
.5- and .75-gallon models. Tank drains with valves
are incorporated on models 1.5-gallon and larger.
• Plastic body, chemical-resistant.
All specifications subject to change without notice. All dimensions are nominal.
All ultrasonic baths meet FCC, CSA, CE & UL rules and regulations.
Standard-two year warranty.
