Features
State-of-the-art Silicon Image (founder of HDMI) chipset embedded for upmost compatibility and reliability
HDMI 1.2a/1.3c* compliant
HDCP compliant
Allows any source to be displayed on multiple displays at the same time
Allows any HDMI display to view any HDMI source at any time
Supports 7.1 channel digital audio
Supports default HDMI EDID and learns the EDID of displays
The matrix master can switch every output channels to any HDMI inputs by push button, IR remote control,
or RS-232 control
Allows controlling local HDMI sources such as DVD and TiVo by IR extender through control path at remote
receiver
Allows to control main matrix center through control line at remote receiver
Extends video signal up to 115 feet (35m) over CAT5e at 1080p
Easy installation with rack-mounting and wall-mounting designs for master and receiver respectively
Specifications & Package Contents
Technical HSW44C HSMR
HDMI compliance
[HSW44C v1.2] – HDMI 1.2a [HSW44C v1.3] – HDMI 1.3c
Yes
Video bandwidth
[HSW44C v1.3] – Single-link 340MHz [6.75Gbps]
480i / 480p / 720p / 1080i / 1080p60
Surround sound (up to 7.1ch) or stereo digital audio
Transmission
Full HD (1080p): 115ft (35m) [CAT5e] / 130ft (40m) [CAT6]
Equalization N/A 8-level digital control
ESD protection
[1] Human body model — ±15kV [air-gap discharge] & ±8kV [contact discharge]
[2] Core chipset — ±8kV
*
HDMI 1.2a for HSW44C v1.2
