Type
Printer
Maximum Original Size
A3
Copy Sizes
Cassette A5R - A3,305x457mm, SRA3, 330x483mm
Stack Bypass 100x148.5mm - 330x483mm
Resolution
Scanning 600dpi x 600dpi
Copying 600dpi x 600dpi
Printing 2400dpi equivalent x 600dpi
256 Gradations
Copy/Print Speed
A4 68 ppm B&W / 16 ppm full colour
A3 28 ppm B&W / 7.8 ppm full colour
First copy time
Black-and-White 5.3 sec
Full Color 12.2sec
Warm-Up Time 8mins and 50secs or less
Multiple Copies/Prints 1 to 9,999 sheets
Duplexing Standard automatic stackless
Paper weight
Deck/Cassette 64 to 209g/m
2
Stack Bypass 64 to 250g/m
2
Duplex
Colour 64 to 163g/m
2
Black & White 64 to 209g/m
2
Cassette
Upper 2 Decks: A4
Lower 2 Universal Cassettes: (A5R to A3,
305x457mm, SRA3, 330x483mm)
Paper Capacity
Standard 1500 sheets x2 Decks 1 & 2 (3000 sheets)
550 sheets x2 Cassettes 3 &4 (1100 sheets)
100 Stack bypass
Optional
Paper deck 3500 sheets
Total paper capacity 7,700 sheets
CPU Canon Custom Processor, 250MHz x 2
Memory 768MB
Hard Disk Drive 40GB
Interface Ethernet (100Base-TX/10Base-T)
Power Supply 230V/10A/50Hz
Power Consumption(W) 1.65 kW maximum
Dimensions (WxDxH) 679x852x1191mm
Weight 226kg
Colour Network Multi-PDL Printer Kit-C1 (Standard for iR 6800CN)
PDL PCL5c, PostScript3 Emulation and UFR
Resolution 2400 equivalent x 600dpi
Memory 768MB (Uses Main unit RAM)
Hard Disk 40GB (Uses Main unit HDD)
CPU Canon Custom Processor 250MHz x 2
(Uses Main unit CPU)
PS Fonts Roman136
PCL Fonts Roman80, Bitmap1, Barcode30, OCR2
Supported OS
PCL Windows 95/98/ME/NT4.0/2000/XP/2003
PS Windows 95/98/ME/NT4.0/2000/XP/2003,
Mac OSX10.2or later
UFR Windows 98/ME/NT4.0/2000/XP/2003
Mac-PPD Mac OS8 or later
Interface Ethernet(100Base-TX/10Base-T),
TokenRing(Optional), USB(Optional),
Network Protocol TCP/IP(LPD/FTP/Port9100/IPP/SMB),
IPX/SPX(NDS, Bindery, NDPS-GW), AppleTalk
Pull Scan Network TWAIN Driver (75 to 600dpi 24bit color/
8bit grayscale/Black & white)
Colour Network Printer Unit-D1 (Standard for iR 6800C)
PDL Adobe PostScript 3, PCL 5c
Resolution 2400 equivalent x 600dpi
Memory 128MB to 256MB(Optional)
Hard Disk 20GB
CPU Intel Mobile PentiumIII 850MHz
PS Fonts Roman138
PCL Fonts Roman78 (including Barcode Fonts)
Supported OS
PS Windows 98/ME/NT4.0/2000/XP/2003,
Mac OS9.0/X
PCL Windows 95/98/ME/NT4.0/2000/XP/2003
Interface IEEE1284, Ethernet(100Base-TX,10Base-T)
Network Protocol TCP/IP(LPD/FTP/Port9100/IPP/SMB/email),
IPX/SPX(NDS, Bindery, NDPS-GW), AppleTalk
Colour Universal Send Kit-C1 (Optional)
Scan Speed 70 ipm: (A4 300dpi compressed PDF),
60 ipm: (A4 300dpi, PDF & JPEG)
Scan Resolution 100dpi, 150dpi, 200x100dpi,
200dpi, 200x400dpi, 300dpi, 400dpi, 600dpi
Destinations E-Mail/Internet FAX (SMTP), PC (SMB, FTP, NCP), iWDM
Address book LDAP, Local (Max.1800)
File Format
Single TIFF, PDF
Multi TIFF, JPEG, PDF
DADF(Standard)
Paper size A3-A5R
Paper weight
Single sided original 42 to 128 g/m
2
Double sided original 50 to 128 g/m
2
Max. Number of originals 100 sheets (80 g/m
2
)
Document Scanning speed 50 ipm (A4, Colour/B&W 600dpi)
70 ipm (A4, Scan, 300dpi, Compressed PDF)
Paper Deck-U1 (Optional)
Paper Size A4
Paper Weight 64 to 209 g/m
2
Paper Capacity 3,500 sheets (80 g/m
2
)
Dimensions (WxDxH) 326x593x574mm
Weight Approx 31kg
Finisher-R1 (Optional)
Number of trays 2 trays (+ optional tray 1)
Tray capacity
A4-A5R 1000 sheets
A3 500 sheets
Staple position Corner, Double
Staple capacity
A4 50 sheets
A3 30 sheets
Dimensions (WxDxH) 536x657x928mm
Weight Approx 40kg
Saddle Finisher-R2 (Optional)
Number of trays 2 trays (+ optional tray 1)
Tray capacity
A4-A5R 1000 sheets
A3 500 sheets
Staple position Corner, Double, Saddle Stitch
Staple capacity
A4 50 sheets
A3 30 sheets
Saddle Stitch Specifications
Paper size A3, A4R
Staple capacity 1 to 15 sheets (60pages, 64-80g/m
2
)
1 to 10 sheets (40pages, 81-105g/m
2
)
Paper weight 64 to 105g/m
2
(64 to 250g/m
2
for Cover page)
Dimensions (WxDxH) 648x657x928mm
Weight Approx 68kg
Other Accessories
Document Tray K1 • Additional Finisher Tray A1 • Puncher Unit -L1 (2 holes), N1 (4 holes) • Shift Tray
C1 • Copy Tray K1 • Staple Cartridge-D3 (for Saddle stich) • Staple Cartridge-J1 • Cassette-AA1 • Card
Reader C1 • Card Reader Attachment Kit C1 • Resolution Switching Board-A2 • USB Interface board A3
(for USB port peer to peer printing) • Colour Network UFR Printer Kit-C1 • 128MB Option Memory Kit
(for Printer-D1) • iR Security Kit • Token Ring Adapter iN-TR2 • Key Switch Unit - D2 • iW Publishing
Manager Software
Environment Compliant with Energy Star
1st ROHS compliant product in the IT industry worldwide
Utilities Netspot Device Installer • Netspot Console
Netspot Job Monitor • Netspot Resource Downloader
Remote User Interface • eMaintenance*
* Please check availability with your local Canon supplier
Ozone less environment frame and parts use chromium free steel plates and screws.
