Chapter 55 Configuring a VoIP Network
Configuring VoIP on a Switch
This example shows how to display the FDL statistics for the specified ports:
Console> (enable) show port voice fdl 7/1-3
Port ErrorEvents ErroredSecond SeverlyErroredSecond
Last 15' Last 24h Last 15' Last 24h Last 15' Last 24h
----- -------- -------- -------- -------- -------- -----------
7/1 17 18 19 20 21 22
7/2 17 18 19 20 21 22
7/3 17 18 19 20 21 22
Port FailedSignalState FailedSignalSecond
Last 15' Last 24h Last 15' Last 24h
----- -------- -------- -------- ---------
7/1 37 38 39 40
7/2 37 38 39 40
7/3 37 38 39 40
Port LES BES LCV
Last 15' Last 24h Last 15' Last 24h Last 15' Last 24h
----- -------- -------- -------- -------- -------- --------
7/1 41 48 49 50 53 54
7/2 41 48 49 50 53 54
7/3 41 48 49 50 53 54
Console> (enable)
Table 55-7 describes the possible fields (depending on the port type queried) in the show port voice fdl
command output.
Displaying the Port Configuration for the Individual Ports
To display the port configuration for the individual ports, perform this task in normal mode:
Table 55-7 FDL Field Descriptions
Field Description
ErrorEvents Count of errored events.
ErroredSecond Count of errored seconds.
SeverelyErroredSecond Count of severely errored seconds.
FailedSignalState Count of failed signal state errors.
FailedSignalSecond Count of errored events.
LES Line errored seconds detected.
BES Bursty errored seconds detected.
LCV Line code violation seconds detected.
Task Command
Display the port configuration for the individual
ports.
show port [mod[/port]]
