Note: Many IR repeater systems do not yet support the stripped-
Note: Many IR repeater systems do not yet support the stripped-
carrier signal format required by your disc player. If yours
does not, a Delta IR Interface may be required to ensure
compatibility between your IR repeater system and your
Delta-series Classé equipment.
Your dealer can assist you in designing an effective IR
The player is designed to respond to IR commands of 5VDC, with the tip
of the mono mini-jacks de–ned to be ≈positive∆ relative to the shank of the
5 DC Trigger Input and Output
Many audio/video components can supply a DC control voltage to
associated equipment in order to induce desired behavior. Your Classé
player can take advantage of these capabilities in order to be switched
automatically, usually in concert with the A/V
standby automatically, usually in concert with the A/V standby
-inch mono mini-jack Trigger In provides for remote-controlled
turn-on (that is, toggling between
standby) of the player.standby
-inch mono mini-jacks provide individually controllable DC
trigger outputs which can be used for any of a number of purposes, as
. For example, your dealer can program
Trigger Out to toggle your Classé power ampli–er between operate and
standby with your disc player.
The remote Trigger In will respond to the presence of 5√12VDC, with tip
Similarly, the Trigger Outs will create a 12VDC signal that can support up
6 Classé CAN Bus Control Ports
These RJ-45 connectors are reserved for future control and communication
applications using Classé Audio»s implementation of the Controller Area
Network (CAN) Bus speci–cation.
