Font and lines per inch (LPI) setup for dierent emulations
Emulation LPI Font(s) Font Default Default Comments
Mode Options Options Size LPI EDR
A799 native 6.00, 6.77, 7.52, 8.13 Standard 13x24 7.52 3 Default setup for monochrome paper
Tall 13x27 6.77 3
ColorPOS
®
13x27 6.77 3 Default setup for two-color paper
A794, A793 6.00, 7.52, 8.13 Standard 13x24 7.52 3
emulation
LEGACY 6.00 Tall 13x27 6.00 7 Default setup for LEGACY emulation
emulation
Standard 13x24 6.00 10
Set interpretation of “Set current color” command
ASCII US ETX SYN ENQ n
Hexadecimal 1F 03 16 05 n
Decimal 31 03 22 05 n
Value of n: 0-FF (Hex)
n = 01 will cause 1B 72 01 to print red. Any other value for 1B 72 will print black.
n = 00 will cause 1B 72 00 to print red and all other values to print black.
This command denes how to interpret the 1B 72 command for legacy environments. It provides a method to resolve
any differences in the denition of command 1B72 between the A799 native mode and earlier implementations in other
printers.
In A799 native mode, the standard “Set current color” command should be used.
Related information
The 1F 03 16 00 command disables this and all other LogoEZ
®
features.
To disable one LogoEZ
®
feature when multiple LogoEZ
®
features are set, rst disable all LogoEZ
®
features and then re-
enable only those you desire.
Print test form
ASCII US t
Hexadecimal 1F 74
Decimal 31 116
Prints the current printer conguration settings on the receipt.
Disabled in page mode.
