60" Fabricated Cutter Deck - Parts List for Figure 6
Ref.
No. Part No. Description Qty.
1 00003107 Cotter Pin, .125 Dia. x 1.0 2
2 00011925 Hex Cap Screw, 3/8-16, 3.75 4
3 01002010 Carriage Screw, 3/8-16 x 1.25 4
4 00012428 Lock Nut, Nylon Insert, 1/2-13 4
5 01002130 Label, 60" 2
6 00022560 Flange Lock Hex Nut, 3/8-16 50
7 00030633 Decal, Rotating Blade 1
8 00030635 Decal, Warning Shield Missing 2
9 01003254 Chute Deflector Rod 1
10 00083192 Idler Washer 1
11 01000343 Complete Wheel, 5.00 Dia. 2
12 01000372 Carriage Bolt, 3/8-16 x .75 Lg. 35
13 01000375 Roller Pin, 1/2 Dia. x 7.31 Lg. 1
14 01000385 Front Roller 5
15 01000398 Wheel Spacer 2
16 01009808 Spacer, .385 x .50 x 3.045 2
17 01000643 Carriage Bolt, 3/8-16 x 1 7
18 01001745 Pin, 5/8 Dia. x 1.2 Lg. 4
19 01003253 Torsion Spring, 0.4ID x 2.16Lg 1
20 01002166 Decal, Danger Hand and Feet 2
21 01002635 Roller Pin 1
22 00013406 Hex Cap Screw, 5/16-18 x .75 1
23 01004304 Hex Index Washer Screw, 3/8-16, .5 8
24 01009300 Chute Bracket 1
25 01008644 Finger Guard 1
26 01004685 Belt Cover Support 2
27 01008814 60 Deck Assembly 1
28 01008633 Left Hand Mount Deck Bracket Assembly 1
29 01005364 Deck Roller Mount Bracket 3
30 01005260 Anti-Scalp Wheel Front Mount Bracket 2
31 01005256 Left Hand Front Roller Mount Bracket 1
32 01005258 Right Hand Front Roller Mount Bracket 1
33 01008635 Right Hand Deck Bracket Assembly 1
34 01005437 Outer Belt Cover Support Assembly 2
35 01006693 Chute Deflector 1
36 01008226 Chute Deflector Bracket 1
37 02000448 Right Hand Deck Belt Cover 1
38 02000447 Left Hand Deck Belt Cover 1
39 01005869 T-Handle Latch Draw 4
40 00017778 Phillips Head Screw, 10-32 16
41 00014608 Lock Nut, Nylon Insert, 10-32 16
42 01006086 Commercial Mower Label 1
43 01001169 Grass Catcher Roller 2
44 02000109 Pillow Block 2
45 01000635 Nut, 5/16-18, Hex Flange Lock 1
46 01004109 Stop Bracket 1
