Replacing Separator Rollers
There are three separator rollers in the multifunction printer which need to be replaced periodically. One is in
the tray and the others are inside the multifunction printer. Basically, all the separator rollers are replaced in
the same way as described in this section.
CAUTION: To prevent electric shock, always turn off the multifunction printer and disconnect
the power cable from the grounded outlet before performing maintenance.
CAUTION: Before performing any of the following procedures, read and follow the safety
instructions in your Owner's Manual or Product Information Guide.
Dell separator rollers are available only through Dell. To
Manual or in this manual.
Dell recommends Dell separator rollers for your multifunction printer. Dell does not provide warranty coverage
for problems caused by using accessories, parts, or components not supplied by Dell.
Removing the Used Separator Roller in Tray
1. Pull the tray out of the multifunction printer until it stops. Hold the tray with both hands, lift the front
slightly, and remove it from the multifunction printer.
NOTE: Remove any print jobs from the tray before pulling the tray out of the multifunction printer.
