Jumpers, Switches, and Connectors 109
Disabling a Forgotten Password
The system's software security features include a system password and a setup password, which are
discussed in detail in "Using the System Setup Program" in your
User's Guide
. The password
jumper enables these password features or disables them and clears any password(s) currently
in use.
CAUTION: See your System Information Guide for complete information about safety precautions,
working inside the computer, and protecting against electrostatic discharge.
1
Turn off the system and attached peripherals, and disconnect the system from the electrical
outlet.
2
Open the system. See "Opening the System" in "Troubleshooting Your System."
3
Remove the password jumper plug.
See Figure A-2 to locate the password jumper on the system board.
4
Close the system. See "Closing the System" in "Troubleshooting Your System."
5
Reconnect the system to the electrical outlet, and turn on the system.
The existing passwords are not disabled (erased) until the system boots with the password
jumper plug removed. However, before you assign a new system and/or setup password, you
must install the jumper plug.
NOTE: If you assign a new system and/or setup password with the jumper plug still removed, the
system disables the new password(s) the next time it boots.
6
Turn off the system, including any attached peripherals, and disconnect the system from the
electrical outlet.
7
Open the system.
8
Install the password jumper plug.
See Figure A-2 to locate the password jumper on the system board.
9
Close the system, reconnect the system to the electrical outlet, and turn on the system.
10
Assign a new system and/or setup password.
To assign a new password using the System Setup program, see "Using the System Setup
Program" in your
User's Guide
.
