Rear panel
See the page indicated in parentheses ( ).
q w e r t y u
o
Q1 Q0Q2 i
q FM/AM antenna terminals ····················································· (18)
w Analog audio connectors ·················································(16 – 18)
e PRE OUT connector ······················································· (5, 29, 30)
r S-VIDEO connector ································································· (18)
t VIDEO connectors ····························································· (16, 17)
y COMPONENT VIDEO connectors ··········································· (17)
u Speaker terminals ························································· (5, 29, 30)
i Power cord ················································································· (5)
o HDMI connectors ·····································································(15)
Q0 Digital audio connectors ··················································· (16, 17)
Q1 REMOTE CONTROL jacks ······················································· (19)
Q2 DOCK CONTROL jack ······························································ (18)
NOTE
Do not touch the inner pins of the connectors on the rear panel.
Electrostatic discharge may cause permanent damage to the unit.
