■ Others
• Simultaneous output possible for all video signals
• Supports PAL and NTSC
Audio Section
■ Advanced AL24 Processing, original Denon technology for high-quality audio
The DVD-3930CI employs Advanced AL24 Processing, the ultimate analog wave-
form reproduction technology developed by Denon, for use during PCM signal
input (during stereo signal processing). In addition to the data expansion of exist-
ing AL24 Processing Plus technology, algorithms developed by Denon for use in
large-capacity calculation processors such as DSPs and FPGAs are used to
interpolate data along the time axis and up-converted sampling is used to achieve
natural interpolation without losing original data. Greater optimization in digital fil-
tering has also been achieved for ringing-free pulse response and for pulsive
music data and attack sounds. This results in more natural reproduction of spa-
tial information such as the delicate nuances in the music, the locations of the
performers, and the breadth, height and depth of the concert hall.
For multi-channel linear PCM audio playback, AL24 Processing Plus technology
works to faithfully reproduce the original sound of recordings.
■ High-accuracy D/A converters for all channels
Two of the latest high-accuracy 24-bit, 192-kHz differential operation D/A con-
verters have been dedicated to the two stereo channels, and three additional
DACs are used for 5.1-channel playback, delivering significantly improved separa-
tion and superior S/N, dynamic range and other aspects of audio performance.
Since highly accurate D/A conversion is achieved for all channels, the sonic result
is refreshingly transparent. During 2-channel stereo playback, these D/A convert-
ers are used in monaural mode, operating as differential output converters inde-
pendently dedicated to the left and right channels, to achieve high-quality play-
back of stereo signals.
■ Pure Direct mode, for greater purity in the audio signal
■ DENON Link 3rd, for high-grade audio transmission
■ HDMI output, for multi-channel audio
■ Bass management function tailored for home theater environments
Construction
■ Construction designed to thoroughly suppress vibration and mutual
interference among circuit blocks
• Three-box layout to isolate circuits and minimize mutual interference
• Thorough vibration-resistant construction
■ DENON original high-accuracy drive mechanism (S.V.H. Mechanism)
Other Features
■ Supports playback of a wide variety of discs
■ Playback frequency ranges of Super Audio CDs are switchable
(50 kHz / 100 kHz)
■
Independent bass management for analog audio output and HDMI audio signals
■ Remote controller with backlight keys
■ Dual Component output (BNC, RCA)
■ Wide pitch pin terminal
Output Terminals For Every A/V System
Video outputs
HDMI: 1
Component: 2 sets (RCA, BNC)
Composite: 1
S-Video: 1
Audio outputs
Optical digital: 1
Coaxial digital: 1
DENON Link: 1
Analog (L/R): 1 set
5.1-channel (FL/FR/C/SL/SR/SW): 1 set
Specifications
Video Section
Signal system
NTSC
Disc played
DVD Audio/Video, Music CD, SuperAudioCD, CD-R/RW(audio/MP3/WMA/JPEG),
Video CD, DVD-R/RW(Video mode/VR mode), DVD+R/RW/Picture CD
Video outputs
Composite Video Output
1.0 Vp-p (with 75 ohms load)
S-Video Output
Y; 1.0 Vp-p (with 75 ohms load),
C; 0.286 Vp-p
Component Video Output Y, Pb/Cb, Pr/Cr:
Y; 1.0 Vp-p (with 75 ohms load),
Pb/Cb; 0.648 Vp-p (with 75 ohms load),
Pr/Cr; 0.648 Vp-p (with 75 ohms load)
Audio Section
Frequency response
DVD
2 Hz - 88 kHz (192 kHz sampling),
2 Hz - 44 kHz (96 kHz sampling),
2 Hz - 22 kHz (48 kHz sampling)
Super Audio CD
2 Hz - 100 kHz
CD, VCD
2 Hz - 20 kHz
Signal-to-noise ratio
120 dB
Dynamic range
110 dB
Total harmonic distortion
0.0008%
General
Power supply
AC 120 V, 60 Hz
Power Consumption
70 W
Dimensions
17.1"(W) x 5.5" (H) x 16"(D),
434 (W)x 139(H) x 407(D)mm
Weight
25.3lbs 11.5kg
DVD-3930CI
* Design and specifications are subject to change without notice.
* Dolby and the double-D symbol are registered trademarks of Dolby Laboratories Licensing Corporation.
* DTS and DTS Digital Surround are registered trademarks of DTS Technology.
* ‘WMA’ (Windows Media Audio) is a audio codec developed by Microsoft. in the United States of America.
* HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC.
* NSV and Super Sub Alias Filter are registered trademarks of Analog Devices, Inc.
* HDCD®, High Definition Compatible Digital® and Microsoft® are either registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries.
* KODAK is a trade mark of Eastman Kodak Company.
* Super Audio CD is a registered trademark of Sony.
