Dual-Speed Stackable Hub Web-based Management User’s Guide
Web-based Network Management72
Getting Started
The first step in getting started in using web-based management for your Hub
is to secure a web-browser. A web-browser is a program which allows a per-
son to read hypertext, for example, Netscape Navigator or Microsoft Internet
Explorer. Follow the installation instructions for the browser.
The second and last step is to configure the IP interface of the Hub. This can
be done manually through a console (see the
In-Band Setup Instructions
on
page 39) or defined in the Boot Configuration File (see Appendix B).
Management
To begin managing your hub stack simply run the web browser you have in-
stalled on your computer and open the IP address you have defined for the
master hub.
In the page that opens, click on the
Login to DFE-2600 series Web-based
Management
button. This opens the main page in the management module.
The top of the main page has a button labeled
Click Here to Load Panel
.
Clicking on this button causes an interactive view of the hub stack front
panel to be shown in the top portion of the window. The three interactive
features of this interactive hub stack (which can also be found in the
Fault -
Group/Port Control
menu option) are described below:
•
Hub ID
