3
Table of Contents
Trademarks
Each name of corporations or products in this book is either a registered trademark or a trademark of its respective
corporation.
Features and Design . . . . . . . . . . . . . . . . . . .2
Table of Contents . . . . . . . . . . . . . . . . . . . . . .3
To the Owner. . . . . . . . . . . . . . . . . . . . . . . . . .4
Safety Instructions . . . . . . . . . . . . . . . . . . . . .5
Air Circulation 6
Moving the Projector 6
Installing the Projector in Proper Directions 7
Compliance . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Part Names and Functions . . . . . . . . . . . . . .9
Front 9
Back 9
Bottom 9
Rear Terminal 10
Top Control 11
Remote Control 12
Remote Control Battery Installation 13
Remote Control Operating Range 13
Adjustable Feet 13
Installation. . . . . . . . . . . . . . . . . . . . . . . . . . .14
Positioning the Projector 14
Connecting the AC Power Cord 15
Connecting to a Computer 16
Connecting to Video Equipment 17
Connecting to Component Video Equipment 18
Basic Operation . . . . . . . . . . . . . . . . . . . . . .19
Turning On the Projector 19
Turning Off the Projector 20
How to Operate the On-Screen Menu 21
Menu Bar 22
Zoom and Focus Adjustment 23
Auto Setup Function 23
Keystone Correction 23
Sound Adjustment 24
Remote Control Operation 25
Computer Input . . . . . . . . . . . . . . . . . . . . .27
Input Source Selection 27
Computer System Selection 28
Auto PC Adjustment 29
Manual PC Adjustment 30
Image Mode Selection 32
Image Adjustment 33
Screen Size Adjustment 34
For zooming in and out the images 35
Video Input . . . . . . . . . . . . . . . . . . . . . . . . . .36
Input Source Selection (Video, S-video) 36
Input Source Selection
(Component, RGB Scart 21-pin) 37
Video System Selection 38
Image Mode Selection 39
Image Adjustment 40
Screen Size Adjustment 42
Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
Setting 43
Maintenance and Cleaning . . . . . . . . . . . . .54
Warning Indicator 54
Cleaning the Filter 55
Resetting the Filter Counter 55
Slide Shutter 56
Cleaning the Projection Lens 56
Cleaning the Projector Cabinet 56
Lamp Replacement 57
Resetting the Lamp Counter 58
Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . .59
Troubleshooting 59
Menu Tree 63
Indicators and Projector Condition 65
Compatible Computer Specifications 66
Technical Specifications 67
Optional Parts 68
Configurations of Terminals 69
Dimensions 69
PIN Code Number Memo 70
