0 = None
A = Filter Clog
B = Smoke Sensor
C = High-Temperature Sensor
D = Filter Clog & Smoke Sensor
E = Filter Clog & High-Temperature Sensor
F = Smoke Sensor & High-Temperature Sensor
G = Filter Clog, Smoke Sensor & High-Temperature Sensor
M M D 92 C 2 C H E L A
2 = 2-Way Chilled Water Valve (Motorized On/Off)
3 = 3-Way Chilled Water Valve (Motorized On/Off)
D = 2-Way Chilled Water Valve (Modulating)
T = 3-Way Chilled Water Valve (Modulating)
H =Canister Humidifier
0 = No Humidifier
R = Remote Humidifier Contact
J = Canister Humidifier &
Remote Humidifier contact
0 = No Reheat
E = Electric Reheat
H = Hot Water Reheat
C = Chilled Water
Nominal Capacity (kBtuh)
D = Disconnect Switch
0 = No Disconnect Switch
M= Microprocessor Control
M = Liebert Mini-Mate2
L = Low Static Blower, 1.5hp Motor
H = High Static Blower, 2hp Motor
A = 460V – 3ph-60Hz
B = 575V – 3ph-60Hz
C = 208V – 3ph-60Hz
D = 230V – 3ph-60Hz
M= 380/415V – 3ph-50Hz
