EPSON Stylus COLOR 3000
Rev. A
A-4
Pin No. I/O Signal Name Description
1 I GAP Platen gap sensor signal
2
GND Ground
Pin No. I/O Signal Name Description
1
+ 5 + 5 VDC
2
GND Ground
3 I ASF_PQ ASF PQ sensor signal
Pin No. I/O Signal Name Description
1 I ASF_PL0 ASF PL sensor signal
2
GND Ground
3 I ASF_PL1 ASF PL sensor signal
4
GND Ground
5 I ASF_PL2 ASF PL sensor signal
6
GND Ground
Pin No. I/O Signal Name Description
1 I IC_Y0 Ink cartridge sensor signal
2
GND Ground
3 I IC_Y1 Ink end sensor signal
4
GND Ground
Pin No. I/O Signal Name Description
1 I IC_C0 Ink cartridge sensor signal
2
GND Ground
3 I IC_C1 Ink end sensor signal
4
GND Ground
Pin No. I/O Signal Name Description
1 I IC_B0 Ink cartridge sensor signal
2
GND Ground
3 I IC_B1 Ink end sensor signal
4
GND Ground
Table A-8. Connector Pin Assignment (CN9)
Table A-9. Connector Pin Assignment (CN10)
Table A-10. Connector Pin Assignment (CN11)
Table A-11. Connector Pin Assignment (CN12)
Table A-12. Connector Pin Assignment (CN13)
Table A-13. Connector Pin Assignment (CN14)
