51
Appendices
Units: dots
* indicates resolutions that are compatible with both analog and digital formats.
*1 This connection is not possible for models which are not equipped with a VGA output port.
RGB Input
Signal Resolution
Aspect
Normal
(Default)
Zoom Through
PC98 640 × 400 1152 × 720 – 640 × 400
EGA 640 × 350 1280 × 700 – 640 × 350
VGA
60 *, SDTV
(525p)
640 × 480
640 × 360 (When zoomed)
960 × 720 1280 × 720 640 × 480
VESA
72/75/85, iMac*1
640 × 480
640 × 360 (When zoomed)
960 × 720 1280 × 720 640 × 480
SVGA
56/60*/72/75/85/, iMac*1
800 × 600
800 × 450 (When zoomed)
960 × 720 1280 × 720 800 × 600
XGA
43i/60*/70/75/85, iMac*1
1024 × 768
1024 × 576 (When zoomed)
960 × 720 1280 × 720 –
1152 × 864
70/75/85
1152 × 864
1152 × 648 (When zoomed)
960 × 720 1280 × 720 –
QVGA
60*/75/85
1280 × 960
1280 × 720 (When zoomed)
960 × 720 1280 × 720 –
SXGA
43i/60*/75/85
1280 × 1024
1280 × 720 (When zoomed)
900 × 720 1280 × 720 –
MAC13” 640 × 480 960 × 720 – 640 × 480
MAC16” 832 × 624 960 × 720 – 832 × 624
MAC19” 1024 × 768 960 × 720 ––
MAC21” 1152 × 870 954 × 720 ––
SDTV
(525i, 60Hz)
640 × 480
640 × 360 (When zoomed)
960 × 720 1280 × 720 590 × 442
SDTV
(625i, 50Hz)
768 × 576
768 × 432 (When zoomed)
960 × 720 1280 × 720 700 × 525
SDTV (625p) 768 × 576
768 × 432 (When zoomed)
960 × 720 1280 × 720 700 × 525
HDTV
(750p)
1280 × 720 1280 × 720 – 1178 × 664
HDTV
(1125i, 1125p)
1920 × 1080 1280 × 720 – 886 × 498
Component Video Input RGB Input
Composite Video/S-Video Input
