Reference Information, cont’d
DVS 150 Reference InformationA-4
Assorted connectors
BNC Connectors
BNC Mini HR crimp connectors, qty. 50 100-074-51
BNC SHR crimp connectors, qty. 50 100-075-51
BNC Bulkhead connectors, qty. 50 100-076-51
(for custom wall plates)
Pre-cut cables
BNC-4 HR cable is used for RGBS cable runs, and BNC-5 is used for RGBHV
cable runs. Either type can also be used for RGsB (sync on green). All
Extron BNC cables have male gender connectors at both ends. A plenum
version of the BNC-5 HR cable is also available.
BNC-4 HR Cable
BNC-4-25’ HR (25 feet/7.5 meters) 26-210-04
BNC-4-50’ HR (50 feet/15.0 meters) 26-210-05
BNC-4-75’ HR (75 feet/23.0 meters) 26-210-06
BNC-4-100’ HR (100 feet/30.0 meters) 26-210-07
BNC-4-150’ HR (150 feet/45.0 meters) 26-210-08
BNC-4-200’ HR (200 feet/60.0 meters) 26-210-09
BNC-4-250’ HR (250 feet/75.0 meters) 26-210-54
BNC-4-300’ HR (300 feet/90.0 meters) 26-210-53
BNC-5 HR Cable
BNC-5-25’ HR (25 feet/7.5 meters) 26-260-03
BNC-5-50’ HR (50 feet/15.0 meters) 26-260-04
BNC-5-75’ HR (75 feet/23.0 meters) 26-260-16
BNC-5-100’ HR (100 feet/30.0 meters) 26-260-05
BNC-5-150’ HR (150 feet/45.0 meters) 26-260-12
BNC-5-200’ HR (200 feet/60.0 meters) 26-260-06
BNC-5-250’ HR (250 feet/75.0 meters) 26-260-18
BNC-5-300’ HR (300 feet/90.0 meters) 26-260-14
