3. If you selected IP [LAN] in step 2, the IP Connection
window appears.
a. Examine the Matrix IP Address eld, which displays
the last Matrix IP address entered.
If necessary, enter the correct IP address in the eld.
N
192.168.254.254 is the factory-specified default value for
this field.
b. If the switcher is password protected, enter the
appropriate administrator or user password in the
Password eld.
c. Click Connect. The Matrix Switchers Control Program
is ready for operation.
Accessing the HTML Pages
Another way to operate the switcher is via its factory-installed
HTML pages, which are always available and cannot be erased
or overwritten. The switcher’s HTML pages are accessible
through its LAN port, connected via a LAN or WAN, using a
web browser such as Microsoft Internet Explorer. See
c
, on
page 2-5, for connection information.
Loading the start-up page
N
If your Ethernet connection to the matrix switcher is
unstable, try turning off the proxy server in your Web
browser. In Microsoft Internet Explorer, click Tools >
Internet Options > Connections > LAN Settings,
uncheck the Use a proxy server... box, and then click OK.
N
For details on operating the switcher via HTML pages,
refer to the FOX 4G Matrix 14400 User's Manual,
chapter 6, “HTML Operation”.
1. Start the Web browser program.
2. Click in the browser’s Address eld.
3. Enter the Matrix IP address in the browser’s Address eld.
N
192.168.254.254 is the factory-specified default value for
this field.
4. Press the keyboard Enter key. The switcher checks to see if
it is password protected.
If the switcher is not password protected, it checks and
downloads the HTML start-up page. The switcher is ready
for operation via HTML remote control.
If the switcher is password protected, it downloads the
Enter Network Password page.
N
A User name entry is not required.
