IN1606 Scaling Presentation Switcher • SIS Communication and Control 36
Command ASCII Command
(host to scaler)
Response
(scaler to host)
Additional Description
Output Configuration Commands
Output scaler rate
Set output rate
EX4(RATE} RateX4(]
Set the output rate from the EDID
emulation X4(.
View output rate
ERATE} X4(]
View the selected output rate.
HDMI output format
Set format
EX@*X3@VTPO} VtpoX@*X3@]
Set the color space and format.
View setting
EX@VTPO} X3@]
View the color space and format
setting.
Power save mode
Power save off
E0PSAV} Psav0]
Operate the IN1606 at full power.
Power save on
E1PSAV} Psav1]
Operate the IN1606 in a low
power state. No video output.
View setting
EPSAV} X3&]
View the IN1606 power mode.
Screen saver
Set mode
EMX2&SSAV} SsavMX2&]
Set the type of screen saver.
View mode
EMSSAV} X2&]
View the selected type of screen
saver.
Set time-out duration
ETX2#SSAV} SsavTX2#]
Set the time-out duration.
View time-out duration
ETSSAV} X2#]
View the time-out duration.
View screen saver
status
ESSSAV} X3*]
View the screen saver status.
NOTES:
X@ = Output selection 1 = HDMI A (top)
2 = HDMI B (bottom)
X2# = Output sync timeout 0 = Output sync is instantly disabled with no active input
1-500 (in 1 second increments)
501 = Output sync never times out
X2& = Screen saver mode 1 = black output (default)
2 = blue output
X3@ = HDMI output format 0 = auto (default)
1 = DVI RGB 444
2 = HDMI RGB “Full”
3 = HDMI RGB “Limited”
4 = HDMI YUV 444 “Full”
5 = HDMI YUV 444 “Limited”
6 = HDMI YUV 422 “Full”
7 = HDMI YUV 422 “Limited”
X3& = Power save mode 0 = full power mode (default)
1 = low power state
X3* = Screen saver status 0 = active input detected; timer not running
1 = no active input; timer running; output sync disabled
2 = no active input; timer expired; output sync disabled
X4( = Output rate See the Output Rate table on page 30.
