Fuse/Relay
Location
Fuse Amp
Rating
Power Distribution Box
Description
102 50A** Cooling fan
103 50A** Instrument panel (I/P) fuse box
feed #1, I/P fuses 23, 25, 27 and 31
104 40A** Instrument panel (I/P) fuse box
feed #2, I/P fuses 1, 3, 5, 7 and 9
105 30A** Starter relay feed
106 40A** Anti-lock Brake System (ABS)
module (Pump)
107 40A** Rear defroster relay feed
108 20A** Moonroof (non-Police vehicles only)
Spotlights (available on Police
vehicles, Long Wheel Base [LWB]
vehicles and commercial vehicles
only)
109 20A** ABS module (Valves)
110 30A** Wiper module
111 50A** Police PDB or Police I/P accessory
battery feed (Police vehicles only)
112 30A** Air suspension compressor
(non-Police vehicles only)
40A** Police PDB relay feed (Police
vehicles only)
113 50A** Police light bar or Police Trunk
accessory battery feed (Police
vehicles only)
114 50A** Police PDB or Police I/P accessory
battery feed (Police vehicles only)
115 50A** Rear power point or Police trunk
accessory battery feed (Police
vehicles only)
116 50A** Police I/P accessory battery feed
(Police vehicles only)
117 50A** Police PDB or Police I/P accessory
battery feed (Police vehicles only)
2005 Crown Victoria (cro)
Owners Guide (post-2002-fmt)
USA (fus)
Roadside Emergencies
193
