COLOR
Fuse
rating
Mini
fuses
Standard
fuses
Maxi
fuses
Cartridge
maxi
fuses
Fuse link
cartridge
50A Red Red Red
60A Blue Yellow Yellow
70A Tan Brown
80A Natural Black Black
Passenger compartment fuse panel
The fuse panel is located below and to the left of the steering wheel by
the brake pedal. Remove the panel cover to access the fuses.
To remove a fuse use the fuse puller tool provided on the fuse panel
cover.
27 25
26 24
23 21
22
19
20
18 16
17 15
14 12
13
10
33
31
29
32
30
28
11
97
8
6
53
4
1
2
Relay
1
2008 Crown Victoria (cro)
Owners Guide (post-2002-fmt)
USA (fus)
Roadside Emergencies
196
