Fuse/Relay
Location
Fuse Amp
Rating
Protected Circuits
116 50A** Police accessory and PDB (Police
vehicles only)
117 50A** Police accessory and PDB (Police
vehicles only)
118 50A** Rear power point or Police
right-hand kick panel accessory
battery feed (Police vehicles only)
201
1
⁄
2
ISO relay A/C clutch
202 — Not used
203
1
⁄
2
ISO relay Ignition coil
204
1
⁄
2
ISO relay PCM
205
1
⁄
2
ISO relay Fog lamps (Grand Marquis only)
206
1
⁄
2
ISO relay Fuel
207 — Not used
208 — Not used
209
1
⁄
2
ISO relay Horn
301 Full ISO relay Starter
302 Full ISO relay Air compressor (non-Police vehicles
only), RUN/ACC relay (Police
vehicles only)
303 Full ISO relay Blower
304 Full ISO relay Rear defrost relay
501 — Not used
502 Diode PCM
503 — Not used
601 20A Circuit
breaker
Power seats, Lumbar, Decklid (Police
vehicles only)
602 20A Circuit
breaker
RUN/ACC relay feed – Windows,
Decklid (Police vehicles only)
* Mini fuse ** Cartridge fuse
