tracer2000 Network DVR Hardware User’s Manual
Version 3.1 Page 24 of 31
2.4 Integrated Peripherals
Use this menu to specify your setting for integrated peripherals.
OnChip Primary PCI IDE Enabled Item Help
OnChip Secondary PCI IDE Enabled
IDE Primary Master PIO Auto
Menu Level ¾
IDE Primary Slave PIO Auto
IDE Secondary Master PIO Auto
IDE Secondary Slave PIO Auto
IDE Primary Master UDMA Auto
IDE Primary Slave UDMA Auto
IDE Secondary Master UDMA Auto
IDE Secondary Slave UDMA Auto
USB Controller Enabled
USB Keyboard Support Enabled
USB Mouse Support Disabled
Init Display Onboard / AGP
AC97 Audio Auto
IDE HDD Block Mode Enabled
Power On Function Button Only
xKB Power On Password Enter
xHot Key Power On Ctrl-F1
Onboard Serial Port 1 3F8 / IRQ4
Onboard Serial Port 2 2F8 / IRQ3
UART Mode Select Normal
xRxD, TxD Active Hi, Lo
xIR Transmission Delay Enabled
xUR2 Duplex Mode Half
xUse IR Pins IR-Rx2Tx2
Onboard Parallel Port 378 / IRQ7
Parallel Port Mode SPP
EPP Mode Select EPP1.7
ECP Mode Use DMA 3
PWRON After PWR-Fail Off
Watch Dog Timer Select Disable
If your IDE hard drive supports
block mode select Enabled for
automatic detection of the optimal
number of block read / write per
sector the drive can support.
↑↓←→Move
F10: Save
F5: Previous Values
Enter: Select
ESC: Exit
F6: Fail-safe Defaults
+/-/PU/PD: Value
F1: General Help
F7: Optimized Defaults
