The user specify SSL private key used for SIP over TLS in X.509 format.
User specify password to protect the private key above.
User specify the Auto Configuration Server’s URL (TR-069 protocol)
User specify the ACS Username
User specify the ACS password
Default is No. If set to YES, device will send inform packets to the ACS
Frequency that the inform packets will be sent out to the ACS
Connection Request
Username
Set a user name for the ACS to connect to this device
Connection Request
Password
Set a password for the ACS to connect to this device
Configuration option is set ring cadence on all FXS ports for all incoming calls. (Syntax:
c=on1/off1-on2/off2-on3/off3(only 3 cadences maximum)) Default is set to c=2000/4000;
(US standards)
Using these settings, users can configure tone frequencies and cadence according to
their preference. By default they are set to North American frequencies. Configure these
settings with known values to avoid uncomfortable high pitch sounds. ON is the period of
ringing (“On time” in ‘ms’) while OFF is the period of silence. In order to set a continuous
tone, OFF should be zero. Otherwise it will ring ON ms and a pause of OFF ms and then
repeat the pattern.
Example configuration for N.A. Dialtone:
f1=350@-13,f2=440@-13,c=0/0;
Syntax: f1=freq@vol, f2=freq@vol, c=on1/off1-on2/off2-on3/off3; [...]
(Note: freq: 0 - 4000Hz; vol: -30 - 0dBm)
Default is No. If set to “Yes”, the configuration update via keypad is disabled.
Default is No. Disables the voice prompt configuration.
Default is No. Disables the Direct IP Call function.
Default is Disable. If Enabled, the unit will start routing the calls to the FXO Gateway
configured via Direct IP Call When it loses registration from your SIP Server. HT704 Only
The use of this option presumes a configured GXW410x or another FXO gateway with an
active PSTN line connection.
IP or Domain Name of the FXO Gateway that will be used as Failover. HT704 Only
URI or IP address of the NTP (Network Time Protocol) server. This parameter
synchronizes the date and time.
Allow DHCP option 42
to override NTP serve
Default NO. Enables the DHCP server to handle the NTP Server via Option 42
The IP address or URL of System log server. This feature is especially useful for the ITSP
(Internet Telephone Service Provider)
