Connecting the Power Adapter
1
Connect the power cord to the power adapter as illustrated.
2 Plug the power adapter connector into the DC-IN on the rear
panel of the TV.
3 Plug the three-pronged plug at the other end of the power cord
into a power outlet.
DV
LINE IN
R
L
LINE OUT
AV1
R L
Rr
Pb
Y
R L
VIEDO
S-VIEDO
AV2
AV3
R L
VIEDO
AN DC IN
DVI LINE IN
R L R L R L VIDEOS-VIDEOYPR PB
LINE OUT
AV 1
AV 2
R L VIDEO ANT DC-IN
AV 3
Power cord
DC-IN
Power outlet
Power adapter
Three-pronged
plug
