NO. DESCRIPTION PART NO. QTY ITEM NOTE
1 Mainframe - Casting 486015V 1
2 Plate - Location RH 480083V 1
3 Clamp - Boss Inner 480084W 2
4 Clamp - Boss Outer 480085W 2
5 Nut - Nyloc Insert âTâ Type 09441 4
6 Key - Woodruff 1662 1
7 Throttle Control 486031 1
8 Engine - B/S Intek edge 55 OHV 486040 1
9 Decal - Engine 486005 1
10 Knob - Handlebar 480088 2
11 Handlebar - Lower 480168W 2
12 Bolt - Handlebar 09785 2
13 Nut - Nylon Insert 09544 1
14 Washer - Plain 09472 1
15 Guide Rope 305093 1
16 Pin - Pivot 340182 2
17 Decal - Grass Blade 410064 1
18 Lever - Engine 340179 1
19 Washer - Nylon 09688 2
20 Handlebar 341029 1
21 Lever - Clutch 306094W 1
22 Screw 09687 2
23 Cable Guide 480123 1
24 Bracket - Cable Clutch 306108 1
25 Screw 09704 1
26 Cable - Clutch 480094 1
27 Grassbag - Assy 486021 1 Includes items 28, 36 & 101
28 Frame - Grassbag 486018W 1
29 Deflector - Rear 480140 1
30 Pin - Roll 03997 1
31 Spring - Deflector RH 480131 1
32 Rod - Deflector 480062 1
33 Screw - Pozi Pan Taptite 09758 2
34 Bolt - Coach 09549 2
35 Knob - HOC 480134 1
36 Grassbag - Fabric 486019 1
37 Spring - Deflector LH 480130 1
38 Plate - Location LH 480082V 1
39 Plate - Handlebar Retainer 480055 2
40 Cover - APTO 480014 1
41 Bearing - APTO 480050 1
42 Screw - Washer Hd Taptite 09575 2
43 Bush 340154 2
44 Screw - Taptite 09349 3
45 Foam Strip 480119 1
46 Lever - HOC 480128 1
1.29
PA RTS LIST
