Print Mechanism Parts
Adjuster
136
C2688-67074 Z-Axis service station alignment - Aligns the carriage when positioned in the service station
137
C4530-40258 Carriage shaft adjuster - Adjusts shaft alignment (Left)
138
C4530-40259 Carriage shaft adjuster - Adjusts shaft alignment (Right)
Belt
139
C4530-40238 Carriage belt
Carriage
140
C2688-67061 Printhead carriage assembly - Includes carriage, carriage PC board, flex cables, line sensor, and carriage belt
Ejector
141
C2688-67012 Paper ejector - Ejects printed paper to the output tray
Gear Assembly
142
C2688-67056 Input gear assembly - Mounts on the left side of the printer - Transfers power to the drive roller
Guide
143
C2688-67043 Upper/rear paper guide assembly - Includes upper and rear paper guides and the envelope switch
Hardware
144
C2688-67063 Carriage shaft shim
Ink Delivery System
145
C2688-67009 Ink Delivery System assembly - Includes ink delivery tubes
Ink Supply Station
146
C2688-67010 Ink Supply Station assembly - Holds the ink cartridges and pumps ink out to the printheads - Includes the ink supply
station motor
Latch
147
C2688-67008 A-arm latch - Retains purple latch over the printheads on the carriage
Lock
148
C2688-67075 Carriage lock - Locks the carriage postion during servicing
Motor
149
C2688-67042 Service station motor
150
C2688-67045 Paper motor assembly
151
C2688-67070 Carriage drive motor - Includes pulley
Pivot
152
C2688-67044 Drive Roller and Pivot Assembly - Includes shaft with four rollers, drive gear, and pivot assembly
Plate
153
C2688-67058 Side Plate Assembly - Mounts on the left side of the chassis - Secures the Input Gear Assembly
154
C2688-67062 Carriage Plate Assembly - Support for the Carriage and Carriage Drive components
Retainer
155
C2688-67047 Retainer ring for drive shaft
156
C4530-40288 Carriage belt retainer
157
C4530-40290 Encoder retainer (snubber)
158
C8119-67008 Retainer (Catwalk) - Holds the paper ejector bar
Roller
159
C2688-67049 Exit pinch roller - Pinches the media against the drive rollers - Mounts in the upper paper guide
160
C4530-40222 Pinch roller - Pinches the media against the drive rollers - Mounts in the rear paper guide
