Step 1 – Choose an EVA Model – Base and Factory-Integration Information
Step 1 – Choose an EVA Model – Base and Factory-Integration InformationStep 1 – Choose an EVA Model – Base and Factory-Integration Information
Step 1 – Choose an EVA Model – Base and Factory-Integration Information
Models
ModelsModels
Models
Enterprise Virtual Array
Enterprise Virtual ArrayEnterprise Virtual Array
Enterprise Virtual Array
4400 Independent
4400 Independent4400 Independent
4400 Independent
Components
ComponentsComponents
Components
The following components are available worldwide. The EVA4400 models are modular and scalable
storage solutions designed to have no-single-point-of-failure, which provide disaster tolerance and
business continuance support for storage consolidation on heterogeneous SANs.
EVA4400 Dual Controller
EVA4400 Dual ControllerEVA4400 Dual Controller
EVA4400 Dual Controller
Array
ArrayArray
Array
HP StorageWorks 4400 Dual Controller Enterprise Virtual Array
One 2U controller enclosure with two HSV300 controller module, mounting
hardware, cables, controller mounting. Order one unit for each EVA4400 array
configuration.
AG637A
EVA4400 Controller Pair
EVA4400 Controller PairEVA4400 Controller Pair
EVA4400 Controller Pair
Enclosure with embedded
Enclosure with embeddedEnclosure with embedded
Enclosure with embedded
switch
switchswitch
switch
HP StorageWorks EVA4400 Dual Controller Enterprise Virtual Array with Embedded
Switch
One 2U Controller Enclosure with two HSV300-S controller module, mounting
hardware, cables, controller mounting. Each controller module also includes an
8Gb/s 10 port B-series SAN switch, for a total of two switches and 20 ports per
controller enclosure. Also included are four 4Gb/s SFPs. Additional 4Gb/s or 8Gb/s
SFPs can be purchased separately. Order one unit for each EVA4400 array
configuration.
AG805A
(available in
Q2 CY08)
M6412 FC Drive
M6412 FC DriveM6412 FC Drive
M6412 FC Drive
Enclosures & Accessories
Enclosures & AccessoriesEnclosures & Accessories
Enclosures & Accessories
HP StorageWorks M6412 Fibre Channel Drive Enclosure
Select up to eight M6412 drive enclosures to expand EVA4400 configurations. Drive
enclosures may be:
Ordered for on-site capacity additions to existing EVA4400 configurations.
Ordered for field installation of complete EVA4400 configurations in
conjunction with the EVA4400 Starter Kits.
Installed by HP manufacturing into EVA configurations by ordering the
enclosure with the factory integration part number (#0D1).
This drive enclosure is compatible with EVA4400 arrays only. Up to eight drive
enclosures are supported with each pair of HSV300 or HSV300-S controllers.
The M6412 is a 2U dual-redundant FC Loop 12-bay disk enclosure with
mounting hardware, and the necessary copper FC cables for connecting to an
HSV300 or HSV300-S Controller pair.
AG638A
NOTE:
NOTE: NOTE:
NOTE:
Minimum of 8 disk drives per Fibre Channel or FATA drive types are required
per EVA4400.
QuickSpecs
HP StorageWorks 4400 Enterprise Virtual Array
HP StorageWorks 4400 Enterprise Virtual ArrayHP StorageWorks 4400 Enterprise Virtual Array
HP StorageWorks 4400 Enterprise Virtual Array
Configuration
DA - 12893 North America — Version 1 — February 26, 2008
Page 23
