3
"The HP Designjet 4520 scanner is specifically designed
for large departments in Enterprise and Public Sector
environments or reprographic houses that print nonstop in
centralized production environments"
Scanner
Superior technology for superior results
• Three digital cameras scan at a resolution of up to 508
dpi optical and 9600 dpi enhanced, with 0.1 percent line
accuracy
• Full, vivid color with 24-bit color and 8-bit graytone
• High-speed, 400 dpi Turbo color scanning at 76 mm (3 in)
per second and 400 dpi Turbo monochrome scanning at
254 mm (10 in) per second
• Scan media up to 1092 mm (43 in) wide and up to 15.2 mm
(0.6 in) thick, for handling oversized, heavyweight originals–
even cardboard
• Color image processing technology provides color correction
and 2-D filters for color sharpening, color softening, and blur
reduction
Software
Complete functionality and control
• Preview your image for a high quality, precision job
• Copy, enlarge, reduce, or adjust colors and settings, for
perfecting even your originals
• Scan to file or DVD/CD in the most common file formats
including PDF, TIFF, JPEG2000, and DWF
• Print your scanned jobs in unattended batches with the
prints-list feature
• Print locally or print through the network to HP Designjet
5x0, 800, 1000, 40x0/45x0, 5x00, T610/T11x0, Z2100/
Z3x00, Z6100 Printer series
• Use the nesting option to save media
• Make enlargements easily with the paneling option
• Track your output using the integrated accounting features
• Perform batch scanning with auto-naming
Graphical display
Convenient, easy-to-use interface
• Touchscreen running embedded operating system
• Intel Pentium 4, 2.6 GHz processor and 40 GB of memory
for scanned jobs
• Small keyboard included for easy data entry and network
access
• DVD/CD reader/writer included for efficiency and versatility
• Fast network connection (TCP/IP)
Support and service
One-stop support and service
• One-year onsite warranty
• Additional support options include physical installation
with or without network configuration, three-year warranty
extension, and a one-year post warranty
• 24-hour online support via www.designjet.hp.com provides
troubleshooting tips, driver downloads, user forums, and
documentation
• Toll-free phone support with product experts
Compatible HP Printer series
HP Designjet 500/510
HP Designjet 500 Mono (AP only)
HP Designjet 800 HP Designjet 1000/1055 HP Designjet 4000/4020
HP Designjet 4500/4520 HP Designjet 5000/5500
HP Designjet 5100 (AP only)
HP Designjet Z6100
HP Designjet Z3100/Z3200 HP Designjet Z2100 HP Designjet T1100/T1120 HP Designjet T610
