LaserJet 8150HN
HP Parts Reference Guide™
www.h
.com/
o/h
arts
External Case Parts
Tray
201
RB1-6490-000CN Face-down output tray - At top of printer
202
RB1-6491-000CN Face-up output tray - At upper left side
203
RG5-4329-000CN Multi-Purpose paper input tray (Tray 1) - Includes pull out extender tray
Feeder Assembly Parts
Arm
204
RB1-6417-000CN Registration paper sensor arm - Senses paper in registration assembly
Cable
205
RG5-1843-000CN Paper sensor cable - J11 to J15
Roller
RB2-3562-000CN Fuser pressure roller - Roller that provides pressure against heating roller in fuser asssembly
Spring
207
RB1-6409-000CN Sensor arm spring - Holds tension on paper feeder sensor arm
RS6-2072-000CN Compression spring - Holds tension on front support block
209
RS6-2073-000CN Compression spring - Holds tension on rear support block
Support
210
RB2-3503-000CN Shaft holding block - Front registration roller support
211
RB2-3504-000CN Shaft holding block - Rear registration roller support
Fusing Assembly Parts
Fusing Assembly
212
C4214-69018 Fusing assembly (For 100V to 120V operation) - Bonds toner to paper with heat
REQUIRES RETURN OF DEFECTIVE PART
RG5-6532-000CN New Part for C4214-69018
213
C4214-69019 Fusing assembly (For 220V to 240V operation) - Bonds toner to paper with heat
REQUIRES RETURN OF DEFECTIVE PART
RG5-6533-000CN New Part for C4214-69019
Lock
RB1-6615-020CN Right fusing assembly lock - Locks fuser in place
RB1-6616-020CN Left fusing assembly lock - Locks fuser in place
Interface Board Parts
PC Board (Interface)
J3110-69001 JetDirect 600N EIO internal print server 10Base-T LAN interface board - Has one RJ-45 connector - (J3110A) - NOTE:
EIO Interface Boards are NOT Interchangeable with MIO Boards
J6057-69001 New Part for J3110-69001
J3111-69001 JetDirect 600N EIO internal print server 10Base-T, 10BASE-2, and LocalTalk LAN interface board - Has one RJ-45,
BNC, and 8-pin DIN connector - (J3111A) - NOTE: EIO interface boards are NOT interchangeable with MIO boards
REQUIRES RETURN OF DEFECTIVE PART
J3111-61001 New Part for J3111-69001
Internal Components
Heater
RH7-4126-000CN Heater element for fusing assembly - 120V
Labels and Transparencies
Film (Transparency)
92296U LaserJet printer transparency film - A4 size (21.0cm x 29.7cm) - 50 sheets per box
92296T LaserJet printer transparency film - A size (8.5 x 11-inches) - 50 sheets per box
