HP Jetdirect EIO Control Panel Menus 40
ENWW
Graphical Control Panel
Graphical control panels
typically display 18 characters
on a line, and as many as four
lines at a time. In addition,
scrolling may be supported to
allow display of additional
lines.
On graphical control panels, a numeric keypad and navigation
buttons are used to access HP Jetdirect EIO menu items. For a
description of menu items and options, see Table C-2
.
Table C-2. EIO Graphical Control Panel Menu (1 of 5)
Menu Item Options Description of settings
TCP/IP ENABLE ● ON: Enable the TCP/IP protocol.
● OFF: Disable the TCP/IP protocol.
HOST NAME Specifies an alphanumeric string, up to 32
characters, used to identify the device.
This name is listed on the Jetdirect
configuration page. The default host name
is NPIxxxxxx, where xxxxxx is the last six
digits of the LAN hardware (MAC)
address.
?
MENUS
+XXXXXXXXXX
+XXXXXXXXXXXX
+XXXXXXXX
