HP LaserJet 8100 Series Printers Specifications
• Two open EIO interface slots for HP JetDirect 600N (EIO)
Internal Print Servers for Fast Ethernet, Ethernet, Token Ring
and LocalTalk environments and accessories, including the
HP EIO disk drive for forms and fonts storage
All HP LaserJet 8100 Series printers:
• Optional HP Infrared Connect (Fast IR) provides IR capabilities
for walk-up, cable-free printing from palmtops, laptop PCs and
other IR-capable devices
• HP JetSend-enabled via EIO, parallel and IR connections.
HP has developed device-to-device communication technology
that enables communication between printers, scanners and a
broad range of other information appliances without a PC
or server
• Automatic switching between languages and ports
• HP Web JetAdmin and HP JetAdmin printer
management software
• Optional HP JetDirect 600N (EIO) Internal Print Servers
for Fast Ethernet, Ethernet, Token Ring and
LocalTalk environments
Memory
HP LaserJet 8100 and 8100 N:
• 16 MB standard RAM with Memory Enhancement
technology (MEt)
HP LaserJet 8100 DN:
• 24 MB standard RAM with Memory Enhancement
technology (MEt)
All HP LaserJet 8100 Series printers:
• Three open 100-pin DIMM slots (two slots on the HP LaserJet
8100 DN) with memory expansion up to 208 MB
• Sufficient standard memory to produce mopies at engine speed
using dynamic RIP-once in RAM
• Optional >2-GB disk drive for storage of print jobs, forms, fonts
and signatures
• Optional 2- and 4-MB flash DIMMs
Printer Languages
• HP PCL 6, HP PCL 5e and PostScript
®
Level 2 emulation
• Automatic language switching
Control Panel
• Expanded Control Panel Help provides detailed troubleshooting
instructions at the printer for intuitive operation and complete,
easy-to-understand messages
• 2 x 16 backlit LCD display
• Buttons: Go, Cancel Job, Menu, Item, Value, Select
• LED indicators: Ready, Data, Attention
• Control panel can be locked through software
• Messages can be displayed in 17 languages: Czech, Danish,
Dutch, English, Finnish, French, German, Hungarian, Italian,
Japanese (Katakana), Norwegian, Polish, Portuguese, Russian,
Spanish, Swedish, Turkish
Font Capabilities
• 110 scaleable TrueType
™
fonts (80 built-in, 30 via HP FontSmart);
all PostScript and HP PCL accessible
• HP FontSmart software provides easy-to-use font management
capabilities for Windows 3.x
• HP Resource Manager provides easy-to-use font and HP PCL 5e
macro download, delete and update capabilities for Windows 95,
Windows 98 and Windows NT 4.0
• Intellifont and TrueType rasterizers built in
• Optional Greek, Hebrew, Cyrillic and Arabic fonts available
for Europe
• Optional Korean, Traditional and Simplified Chinese fonts
available for Asia
Environmental Ranges
Temperature for Printer and Toner:
Operating 10° to 32.5° C (50° to 91° F)
Storage: 0° to 35° C (32° to 95° F)
Humidity for Printer and Toner:
Operating 20% to 80% RH
Storage 20% to 80% RH
Acoustics:
• Operating position: L
pAm
59 dB (A) printing, L
pAm
41 dB (A) stand-
by (per ISO 9296, DIN 45635, T.19)
• Bystander 1m: L
pAm
53 dB (A) printing, L
pAm
36 dB (A) standby
(per ISO 7779, DIN 45635, T.19)
• Sound Power: L
WAd
= 6.9 bels (A) operating (per ISO 9296),
L
WAd
= 5.2 bels standby
Power Requirements
Source:
• 100 to 120 volts (+/- 10%), 50/60 Hz (+/- 2 Hz)
127 volts, 60 Hz NOM or 220 to 240 volts (+/- 10%),
50 Hz (+/- 2 Hz) 220 volts (+/- 10%), 60 Hz (+/- 2 Hz)
• Printer’s voltage ranges depend upon the country in which the
printer is purchased
Minimum Circuit Capacity:
• 115 volts @ 15 amps or 230 volts @ 6.5 amps
Power Consumption:
• 110 v. HP LaserJet 8100 base printer; 700 watts printing;
145 watts standby; 29 watts Powersave mode;
HP LaserJet 8100 N adds 3 watts to base,
HP LaserJet 8100 DN adds 6 watts to base
• 220 v. HP LaserJet 8100 base printer; 710 watts printing;
145 watts standby; 32 watts Powersave mode;
HP LaserJet 8100 N adds 3 watts to base,
HP LaserJet 8100 DN adds 6 watts to base
• U.S. EPA ENERGY STAR qualified
Dimensions (H x W x D)
566 x 520 x 540 mm (22.3 x 20.5 x 21.6 in)
Weight
HP LaserJet 8100 and HP LaserJet 8100 N:
• 51 kg (113 lb) without cartridge; 54 kg (120 lb) with cartridge
HP LaserJet 8100 DN:
• 55 kg (121 lb) without cartridge; 58 kg (128 lb) with cartridge
Product Certifications
UL/cUL listed to UL 1950 and CSA C22.2 No. 950 (1995); com-
plies with IEC 950/EN 60950 including A1, A2, A3, A4; FCC Class
B certified, CISPR-22 level B, Product CDRH certified Class 1
Laser Product (safe for office/EDP use)
