Use the printer control panel
This section contains the following topics:
•
Overview of buttons and lights
•
Change printer settings
•
Print reports
Overview of buttons and lights
For more information about control panel light patterns and messages, see Control panel
lights reference.
2134
12
5
6
7
911 810
Label Name and Description
1 Printhead align control panel icon. Shows that the printhead requires alignment.
2 Ink cartridge access door open icon. Shows that the printer's ink cartridge access door or top
cover is open.
3 Out of paper icon. Shows that the printer is out of paper.
4 Paper jam icon. Shows that the printer has a paper jam.
5 Resume button and light. The Resume light blinks when the button must be pressed to resume
printing. Press to continue a print job after clearing a paper jam, adding paper, or installing a
cartridge. Press to cancel a print job when a media size mismatch occurs. Press and hold for
three seconds to print a demo page.
6 Cancel button. Press once to stop a print job, or press and hold for three seconds to print a
printer status report.
7 Power button and light. Press to turn the printer on or off. The light indicates whether the printer
is on or off.
