Processor
NOTE: The processor spare part kit includes replacement thermal material. Replacement thermal
material is also available in the Thermal Material Kit, spare part number 634366-001.
Description Spare part number
Intel Quad Core i7-3820QM 2.70-GHz processor (SC turbo up to 3.70-GHz; 1600-MHz FSB, 8.0-
MB L3 cache, 45 W)
681284-001
Intel Quad Core i7-3720QM 2.60-GHz processor (SC turbo up to 3.60-GHz; 1600-MHz FSB, 6.0-
MB L3 cache, 45 W)
681283-001
Intel Quad Core i7-3612QM 2.10-GHz processor (SC turbo up to 3.10-GHz; 1600-MHz FSB, 6.0-
MB L3 cache, 35 W)
680647-001
Intel Quad Core i7-3610QM 2.30-GHz processor (SC turbo up to 3.30-GHz; 1600-MHz FSB, 6.0-
MB L3 cache, 45 W)
680646-001
Intel Quad Core i7-2860QM 2.50-GHz processor (SC turbo up to 3.60-GHz), 8.0-MB L3 cache,
1600-MHz FSB, 45 W
666175-001
Intel Quad Core i7-2760QM 2.40-GHz processor (SC turbo up to 3.50-GHz), 6.0-MB L3 cache,
1600-MHz FSB, 45 W
666174-001
Intel Quad Core i7-2670QM 2.40-GHz processor (SC turbo up to 3.50-GHz), 6.0-MB L3 cache,
1600-MHz FSB, 45 W
665116-001
Intel Quad Core i7-2640M 2.80-GHz processor (SC turbo up to 3.10-GHz), 4.0-MB L3 cache,
1333-MHz FSB, 35 W
666173-001
Intel Dual Core i5-3210M 2.50-GHz processor (SC turbo up to 3.10-GHz; 1600-MHz FSB, 3.0-MB
L3 cache, 35 W)
680645-001
Intel Dual Core i5-2450M 2.50-GHz processor (SC turbo up to 3.10-GHz), 3.0-MB L3 cache, 1333-
MHz FSB, 35 W)
676359-001
Intel Dual Core i5-2430M 2.40-GHz processor (SC turbo up to 3.00-GHz), 3.0-MB L3 cache, 1333-
MHz FSB, 35 W
653341-001
Before removing the processor, follow these steps:
1.
Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn
the computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3.
Disconnect the power from the computer by first unplugging the power cord from the AC outlet
and then unplugging the AC adapter from the computer.
4. Remove the battery (see
Battery on page 39), and then remove the following components:
a. Subwoofer (see
Subwoofer on page 41)
b. Hard drive (see
Hard drive on page 51)
c. Top cover (see
Top cover on page 56)
