Step 6 - Configure Packaging Options
Step 6 - Configure Packaging OptionsStep 6 - Configure Packaging Options
Step 6 - Configure Packaging Options
Step 6a - Redundant (N+1) Power Supplies
Step 6a - Redundant (N+1) Power SuppliesStep 6a - Redundant (N+1) Power Supplies
Step 6a - Redundant (N+1) Power Supplies
Power supplies included with Model 24 and Model 32 systems can support all combinations of CPUs, memory, and I/O that can be configured
within the system boxes.
Additional 48V power regulators can be ordered to provide N+ 1 power redundancy.
For Model 24 systems, order three power supplies to achieve N+ 1 capability; for Model 32 systems, order four power supplies to achieve N+1
capability.
2000W 48V power supply
H7506-BA
Step 6b - Internal System Expansion
Step 6b - Internal System ExpansionStep 6b - Internal System Expansion
Step 6b - Internal System Expansion
AlphaServer GS320 Model 24 and Model 32 systems support two additional shelves in the power cabinet
Available choices are:
One additional PCI drawer (master or expansion)
One additional PCI drawer (master or expansion) and one DS-SL13R-xx StorageWorks shelf, or
One or two StorageWorks DS-SL13R-xx shelves
Mixed configurations of BA36R and DS-SL13R-xx shelves are supported
Internal StorageWorks
Internal StorageWorksInternal StorageWorks
Internal StorageWorks
Expansion
ExpansionExpansion
Expansion
System power cabinet provides space for up to two forward facing storage shelves.
Up to two DS-SL13R-xx Ultra3 SCSI (LVD) shelves; each shelf supports a maximum of 14
Ultra3 disk drives
Configuring
ConfiguringConfiguring
Configuring
DS-SL13R-xx Ultra3 (LVD)
DS-SL13R-xx Ultra3 (LVD)DS-SL13R-xx Ultra3 (LVD)
DS-SL13R-xx Ultra3 (LVD)
Shelves
ShelvesShelves
Shelves
Each single-bus Ultra3 shelf requires a 3X-KZPCA-AA Ultra2 (LVD) SCSI adapter or DS-KZPCC-
xx RAID controller and a SCSI cable to connect controller to shelf
Each split-bus Ultra3 shelf requires two 3X-KZPCA-AA Ultra2 (LVD) SCSI adapters, at least one
dual-channel 3X-KZPEA-DB Ultra3 (LVD) SCSI adapter, or DS-KZPCC-xx RAID controllers and
SCSI cables to connect controller to shelf
Ultra3 shelves connected to 3X-KZPCA-AA adapters in the power cabinet require BN38C-02
2-meter cables; DS-KZPCC-xx RAID controllers require BN37A-02 2-meter cables.
Ultra3 shelves connected to 3X-KZPCA-AA adapters in an attached expander cabinet require
BN38C-10 10-meter cables; DS-KZPCC-xx RAID controllers require BN37A-10 10-meter
cables.
Ultra3 shelves connected to 3X-KZPCA-AA adapters in a remote expander cabinet require 10
20-meter BN38C-xx cables, depending upon physical cabinet location; DS-KZPCC-xx RAID
controllers require BN37A-xx cables.
Ultra3 Universal drives are listed in a subsequent section
StorageWorks Model 4314R Ultra3 SCSI (LVD) single-bus Universal drive rackmount shelf,
International except Japan
DS-SL13R-AA
StorageWorks Model 4314R Ultra3 SCSI (LVD) single-bus Universal drive rackmount shelf, Japan
DS-SL13R-AJ
StorageWorks Model 4354R Ultra3 SCSI (LVD) split-bus Universal drive rackmount shelf, International
except Japan
DS-SL13R-BA
StorageWorks Model 4354R Ultra3 SCSI (LVD) split-bus Universal drive rackmount shelf, Japan
DS-SL13R-BJ
NOTE:
NOTE: NOTE:
NOTE:
Model 4314 shelf with DS-KZPCC-CE RAID controller does not support a disk drive in the last slot.
QuickSpecs
HP AlphaServer GS320 (1224 MHz)
Options
DA - 11424 North America — Version 7 — August 19, 2003
Page 11
