A-1
Specifications
A
Specifications
Physical (includes bulkhead and connector):
Environmental:
Connectors:
The RS-232-C console port conforms to V.22 bis.
Electromagnetic:
Emissions:
FCC part 15 Class A
CISPR-22 Class A/EN 55022 Class A
VCCI Level 1
Immunity:
(See the Declaration of Conformity at the end of the Safety and Regulatory
Statements in the HP AdvanceStack Switch 208/224 Installation and
Reference Guide.)
Width 16.7 cm (6.6 in)
Depth 18.3 cm (7.2 in)
Height 4.5 cm (1.8 in)
Weight 2.3 kg (.50 lb)
Operating Non-Operating
Temperature +0
°C to +55°C
(32
°F to 131°F)
-40
°C to 70°C
(-40
°F to 158°F)
Relative humidity
(non-condensing)
15% to 95%at 40
°C (104°F) 15% to 90%
at 65
°C (149°F)
Maximum altitude 4.6 km (15,000 ft) 4.6 km (15,000 ft)
