HP LaserJet P1006 Printer
Technical specifications HP LaserJet P1006 Printer (CB411A)
Print speed
4
Up to 17 ppm letter (up to 16 ppm A4)
First page out Less than 8.5 seconds from PowerSave mode
Resolution, enhancement
technologies
Up to 600 by 600 dpi (1200 dpi effective output); REt, HP FastRes 600 (600 dpi effective output), HP FastRes 1200
(1200 dpi effective output)
Processor 266 MHz
Memory 8 MB embedded inside SIP ASIC, 16 k bit NVRAM
Recommended monthly volume
5
250 to 1,500 pages
Maximum monthly duty cycle
6
Up to 5,000 pages
Languages Host-based
Paper
Input 150-sheet adjustable main tray, 10-sheet priority input tray
Output 100-sheet output bin
Two-sided printing Manual two-sided printing
Sizes Adjustable main tray: A4, A5, A6, B5, 16K; letter, legal, executive; postcards, envelopes (C5, DL, B5, No. 10, Monarch);
custom: 5.8 by 8.27 in (147 by 211 mm) to 8.5 by 14 in (216 by 356 mm)
10-sheet priority input tray: A4, A5, A6, B5, 16K; letter, legal, executive; postcards, envelopes (C5, DL, B5, No. 10,
Monarch); custom: 3 by 5 in (76 by 127 mm) to 8.5 by 14 in (216 by 356 mm)
Weights 60 to 163 g/m
2
(16 to 43 lb bond)
Types Paper (laser, plain, photo, rough, vellum, archive), envelopes, labels, cardstock, transparencies
Connectivity
Interfaces Hi-Speed USB 2.0 port
Operating systems Windows® 2000, XP Home, XP® Professional, XP Professional x64; Windows Server 2003 (32/64 bit);
Works with Windows Vista; Mac OS X v10.2.8, v10.3, v10.4 and higher
Dimensions (w by d by h) 347 by 224 by 194 mm (13.66 by 8.82 by 7.64 in)
Weight (without print cartridge) 4.7 kg (10.3 lb)
What’s in the box HP LaserJet 1006 Printer, introductory HP LaserJet print cartridge,
7
Getting Started Guide, printer documentation and
software on CD-ROM, support flyer, power cord
Warranty One-year limited warranty
Environmental ranges
Recommended temperature 10 to 32.5 degrees C (50 to 90.5 degrees F)
Storage temperature 0 to 40 degrees C (32 to 104 degrees F)
Operating relative humidity 10 to 80 percent
Altitude 0 to 3,100 m (0 to 10,000 ft)
Acoustics
8
Sound power Active: 6.3 B(A); Ready: inaudible
Bystander sound pressure Active: 50.6 dB(A), Ready: inaudible
Power specifications
9
Required input voltage 110 to 127 V (±10 percent), 60 Hz (±2 Hz), 7 amp
220 to 240 V (±10 percent), 50 Hz (±2 Hz), 4.0 amp
Power consumption Active: 335 watts Ready: 3 watts Sleep: 3 watts
Off: 0.6 watts
Typical Electricity Consumption (TEC): 0.793 KWhr/Week
ENERGY STAR
®
qualified models; see www.hp.com/go/energystar
Certifications
Safety IEC 60950-1 (International), EN 60950-1 +A11 (EU), IEC 60825-
1+A1+A2, UL/cUL Listed (US/Canada), GS License (Europe), EN
60825-1+A1+A2 Class 1, 21 CFR Ch. 1/SubCh. J & Laser Notice
#50 (July 26th 2001) (Class 1 Laser/LED Device) GB4943-2001,
Low Voltage Directive 2006/95/EC with CE Marking (Europe).
Other safety approvals as required by individual countries.
EMC CISPR 22: 2005/EN 55022: 2006 Class B, EN 61000-3-2: 2000
+A2, EN 61000-3-3: 1995+A1, EN 55024: 1998+A1 +A2, FCC
Title 47 CFR, Part 15 Class B (USA), ICES-003, Issue 4, (Canada),
GB9254-1998, EMC Directive 2004/108/EC with CE Marking
(Europe), other EMC approvals as required by individual countries.
HP SureSupply enabled: To learn more, please visit www.hp.com/go/suresupply
4
Speed specification per industry standard testing methods.
5
HP recommends that the number of printed pages per month be within the stated range for optimum device performance, based on factors including supplies replacement intervals and device life
over an extended warranty period.
6
Duty cycle is defined as the maximum number of pages per month of imaged output. This value provides a comparison of product robustness in relation to other HP LaserJet or HP Color LaserJet
devices, and enables appropriate deployment of printers and MFPs to satisfy the demands of connected individuals or groups.
7
Average cartridge yield 700 standard pages. For page and photo yields and other cartridge options, see www.hp.com/go/pageyield.
8
Measured per ISO 7779 and declared per ISO 9296; values subject to change. For current information see www.hp.com/support. Configuration tested: base model, printing on A4 paper at
17 ppm.
9
Power reported is the highest value measured using all standard voltages.
ENERGY STAR and the ENERGY STAR mark are U.S. registered marks. Microsoft, Windows, and Windows XP are U.S. registered trademarks of Microsoft Corporation. Windows Vista is
either a registered trademark or trademark of Microsoft Corporation in the United States and/or other countries.
© Copyright 2007 Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without notice. The only warranties for HP products and services are set forth in the express warranty statements accompanying
such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
To learn more, visit www.hp.com
0000-0000ENUC, August 2007, Rev. 1
