2 Cabling HP 3PAR StoreServ 7000/7450
The following illustrative sections provide a rear view of the rack with recommended racking
configuration of the system.
2 Node 1 Drive Enclosures (1L)
Before you begin cabling the storage system, carefully read or print the following section, including
figures 1 and 2, “Identifying and Labeling the Components” (page 4).
2 Node 1 Drive Enclosures (1L) 7
