29
Chapter 3 Installing and Configuring
6. Remove the new DIMM from its container, handling the module by its edges.
Use only HP PC2100 (266 MHz) buffered ECC DDR DIMMs.
Figure 3-12. DIMM Locations on System Board
CAUTION The DIMM should be left in the anti-static container or placed
on an anti-static surface, until you are ready to install it into
the DIMM slot.
DIMM
1
2
3
4
