F300E ELECTRONIC AIR CLEANER WITH ENHANCED FILTRATION
68-0240EF—3 16
REPLACEMENT PARTS (TABLE 3)/EXPLODED VIEW (FIG. 18)
a
Use 203365A Conversion Kit for changing 120V, 60 Hz power supply to 240V, 60 Hz or 220V/240V, 50 Hz.
(#) = Quantity required per unit. N/A = Not available as merchandised part.
Table 3. Replacement Parts.
No.
Nominal Return Air Opening
Description
16 x 20 in.
(406 x 508 mm)
16 x 25 in.
(406 x 635 mm)
20 x 20 in.
(508 x 508 mm)
20 x 25 in.
(508 x 635 mm)
1 Access Door 32007528-003 32007528-003 32007528-002 32007528-002
2 Test Button Assembly 203306AB (1) 203306AB (1) 203306AB (1) 203306AB (1)
3 Electronic Cell FC37A1114 (2) FC37A1130 (2) FC37A1049 (2) FC37A1064 (2)
4 Cell Handle 137266 (2) 137266 (2) 137266 (1) 137266 (1)
5 Prefilter 209989 (2) 203371 (2) 203373 (2) 203372 (2)
6 Cell Key 136518 (1) 136518 (1) 136518 (1) 136518 (1)
7 Power Box Assembly
(includes no. 8-20),
120V, 60 Hz
208418J (1) 208417S (1) 208418H (1) 208417R (1)
8 Switch 203321 (1) 203321 (1) 203321 (1) 203321 (1)
9 Power Box Cover and Label 32004930-002 32004930-001 32004930-002 32004930-001
10 Power Supply, 120V, 60 Hz 208414G (1) 208414B (1) 208414B (1) 208414A (1)
11 Interlock Bracket and Switch 4074ETG (1) 4074ETG (1) 4074ETG (1) 4074ETG (1)
12 W8600 Terminal Strip Supplied with W8600F
13 Terminal Board Assembly
Front
203329B (1) 203329B (1) 203329B (1) 203329C (1)
14 Terminal Board Assembly
Rear
203329A (1) 203329A (1) 203329A (1) 203329A (1)
15 Barrier Plate 203331 (1) 203331 (1) 203331 (1) 203331 (1)
16 Strain Relief 203852 (1) 203852 (1) 203852 (1) 203852 (1)
17 Line Cord 4074ETD (1) 4074ETD (1) 4074ETD (1) 4074ETD (1)
18 Hole Plug 203847 (1) 203847 (1) 203847 (1) 203847 (1)
19 Neon Assembly 4074EYS (1) 4074EYS (1) 4074EYS (1) 4074EYS (1)
20 Airflow Switch 4074ETH (1) 4074ETH (1) 4074ETH (1) 4074ETH (1)
21 Media Postfilter 50000293-001 50000293-002 50000293-003 50000293-004
22 FC37A Bag Assembly for cell
repair: 2 connector clips, 1
terminal board, instructions.
4074EHG 4074EHG 4074EHG 4074EHG
