302620 8/06 10-3
Seat Installation
NOTES:
1. Must pivot freely.
2. Service parts available for Michigan seats:
3. Service parts available for Milsco seats:
INDEX
NO.
SERVICE
PART NO.
MFG. PART
NO.
QTY. DESCRIPTION
1 036244 036244 1 CS .375-16 X 1.00 HX G5 ZNYC
2 767954 767954 5 FW .406 X .812 X .060 SAE HD ZN
3 748756 748756 1 SPRING PLUNGER LATCH
4 389940 389940 1 SEAT LATCH BRACKET
5 781617 781617 3 RUBBER BUMPER
6 722199 722199 1 2" WIDE SCOTCH POLYURETHANE 6"
7 792051 792051 1 SEAT
8 000331 000331 3 SMALL/SHORT WIRE TIE
9 086660 086660 3 NT .375-16 HX LK NY
10 724716 724716 1 FIBER WASHER
11 350421 350421 1 SEAT PAN STOP
12 388983 388983 1 SEAT PAN
13 768523 768523 4 FW .343 X .687 X .051/.080 HD ZNYC
14 034272 034272 4 NT .312-18 HX G5 ZNYC
15 080358 080358 1 GM .50 X 1.00 X .75 X .12
16 781880 781880 2 .500 X 1.00X .312 X.188 BUMPER
17 052860 052860 2 CS .375-16 X 1.25 HX G5 ZNYC
18 768523 768523 2 FW .343 X .687 X .051/.080 HD ZNYC
19 055822 055822 2 CS .375-16 X .75 HX G5 ZNYC
PART NO.
DESCRIPTION
793307 SLIDE KIT
793323 KNOB KIT
793281 BACK CUSHION KI
793299 SEAT CUSHION KIT
797571 SEAT BACK PANEL KIT
793315 SEAT SWITCH
797480 ONE ARMREST (ROUND STYLE W/O BRACKET))
793265 ONE ARMREST (SQUARE STYLE W/O BRACKET)
793273 ARMREST STOP ASSEMBLY
PART NO.
DESCRIPTION
782144 ADJUSTER, STANDARD AND LOW PROFILE SUSPENSION SEAT
782177 OPERATOR PRESENCE SWITCH
783472 Z ARMREST ONLY KIT
