51
12
COMMANDMIC II™ HM-157
12
■ Channel comments
q Push [
YY
] or [
ZZ
] to select a channel to program a channel
comment.
• While pushing [H/L], push [CH/WX• U/I/C] several times to
select the channel group (USA, INT, CAN), if desired.
w While pushing [CH/WX• U/I/C], push [16•9].
• Acursor and the first character start blinking alternately.
e Select the desired character by pushing [Y] or [Z].
• Push [SQL] or [VOL• PA/RX ] to move the cursor forward
or backward, respectively.
r Repeat step e to input all characters.
t Push [16•
9] to input and set the comment.
• Push [CH/WX• U/I/C] to cancel.
• The cursor and the character stop blinking.
y Repeat steps q to t to program other channel com-
ments, if desired.
• Available characters
■ HM-157 supplied accessories
Accessories included with the HM-157: Qty.
q Connection cable (OPC-1000: 6 m; 20 ft) ...................... 1
w Mounting base ................................................................ 1
e Microphone hanger ........................................................ 1
r Screws (M3 × 16; tapping) ............................................. 5
