EN37
Controls
1 Diopter Adjustment Control ................. ੬ pg. 13
2 Lens Cover Open/Close Ring................ ੬ pg. 14
3 5-Second Recording Button
[5 SEC. REC] ........................................ ੬ pg. 17
4 Power Zoom Lever [T/W]..................... ੬ pg. 16
5 •Picture Stabilizer Button
[P.STABILIZER] .................................. ੬ pg. 16
•Time Base Corrector Button ............... ੬ pg. 29
6 Program AE Button [P.AE]..................... ੬ pg. 19
7 Fade/Wipe Button [EFFECT] ................. ੬ pg. 18
8 •Retake Rewind Button [RETAKE R]..... ੬ pg. 17
•Quick Review Button [ R] ............. ੬ pg. 17
•Rewind Button [REW] ....................... ੬ pg. 28
9 •Retake Forward Button [RETAKE F] .... ੬ pg. 17
•Fast-Forward Button [FF] ................... ੬ pg. 28
0 Stop Button [STOP] .............................. ੬ pg. 28
! Play/Pause Button [PLAY/PAUSE] ......... ੬ pg. 28
@ Select Wheel [PUSH]........................... ੬ pg. 20
# MENU/DISPLAY Button ................. ੬ pg. 15, 20
$ •Recording Mode Button [SP/EP] ......... ੬ pg. 12
•Counter Reset/Memory Button
[COUNTER R/M] .............................. ੬ pg. 29
% EJECT Switch ....................................... ੬ pg. 10
^ Recording Start/Stop Button.................. ੬ pg. 14
& Power Switch
[ , OFF, AUTO, PRO.] .............. ੬ pg. 14, 28
* Battery Release Switch
[BATTERY RELEASE] .............................. ੬ pg. 9
( PUSH Button ....................................... ੬ pg. 10
Connectors
) DC IN Connector................................... ੬ pg. 9
The connectors q to e are located beneath the
cover.
q Video Output Connector...................... ੬ pg. 30
w Audio Output Connector ..................... ੬ pg. 30
e J Terminal [JLIP (Joint Level Interface Protocol)
Connector]
•It is used to connect the camcorder to a device
such as a personal computer.
For further details consult your nearest JVC
dealer.
•JLIP-controlled editing from camcorder to VCR
is not possible if the VCR is not equipped with a
J terminal.
Indicators
r Power Lamp ........................................ ੬ pg. 14
Other Parts
t Battery Pack Mount ............................... ੬ pg. 9
y Viewfinder........................................... ੬ pg. 13
u Grip Strap............................................ ੬ pg. 13
i Camera sensor
Be careful not to cover this area; a sensor
necessary for shooting is built-in here.
o Microphone
For use when recording.
p Eyepiece.............................................. ੬ pg. 33
Q Shoulder Strap Eyelets.......................... ੬ pg. 13
W Clock Battery Slot ................................ ੬ pg. 10
E Tripod Mounting Socket....................... ੬ pg. 13
